Información general

DTS Interactive
DTS Neo:PC
Dolby Virtual Speaker
Dolby Digital Live
PCI 2.2 compliant

La tarjeta de sonido Club 3D Theatron Agrippa DTS 7.1 está diseñado para el audiófilo, buscando el mejor sonido y una extrema experiencia de sonido surround. Con el Theatron Agrippa disfrutaras de audio en alta resolución digital en la reproducción de juegos, música o películas. Con salida óptica y coaxial digital y apoyados con una serie de ocho salidas analógicas discretas que ofrecen sonido envolvente 7.1, le permite transferir datos de audio digital para amplificadores externos sin pérdida de calidad de audio. Digital en tiempo real y las características DTS Connect y Dolby Digital Live le ofrecen una alta fidelidad de sonido surround en su entorno. Club 3D Theatron Agrippa DTS 7.1 tiene la capacidad de actualizar su PC a un producto de alta calidad para un Home Entertaintment Center.

DTS Digital Surround®

Sound format found in movie theaters. The Club 3D Theatron Agrippa DTS 7.1 turns your PC into a DTS-Connect enabled PC capable of playing full surround sound from DTS-enabled movies, music videos, music discs, and games, as well as providing surround sound from normal stereo sources.

DTS Connect®

With more personal computers being used as home media centers, Club 3D Theatron Agrippa DTS Connect is the perfect solution to enhance your entertainment experience using sound card throught your home theater's Audio/Video Receiver. DTS Connect is comprised of two DTS technologies:

DTS Neo: PC™ takes 2-channel (stereo) audio and transforms it into a full-bandwidth matrix of your speaker layout (up to 7.1 channels)
DTS Interactive™ encodes digital audio sources into DTS Digital Surround, which can then stream out to your Audio/Video Receiver using a S/PDIF connection.

Dolby® Digital Live

Enjoy audio from your PC through your home theater with Dolby® Digital Live. A real-time encoding technology, Dolby Digital Live converts any audio signal into a Dolby Digital bitstream for transport and playback through a home theater system. With it, your PC can be hooked up to your Dolby Digital-equipped audio/video receiver or digital speaker system via a single digital connection, eliminating the confusion of multiple cables and ensuring the integrity of the audio signal.

DTS® Interactive - Real-time 5.1 channel encoder
DTS® Neo:PC - An upmix matrix technology
Dolby® Digital Live (DDL) - Real-time 5.1 channel encoder
C-Media Xear 3D™ EX supports Direct Sound 3D positional sounds and EAX 2.0 on Vista and legacy Windows
C-Media Xear 3D 7.1 Virtual Speaker SHIFTER technology
Unique Karaoke functionality: Mic Echo, Key-shifting, Vocal Cancellation
Magic Voice™ feature to change users' voice tone for IP phone, online games and messenger applications
10-band Equalizer with 12 preset modes; 27 global environment effects
Supports multi-speaker output to 2 / 4 / 5.1 / 7.1 speakers
DirectSound™3D
EAX v2.0 & A3D v1.0
8 channel output capability supports the newest Dolby® Digital EX and DTS® ES DVD audio format.

PDF Download:

Theatron Agrippa DTS 7.1 Product Information sheet (EN)

High Resolution Image:

Theatron Agrippa DTS 7.1

Especificaciones

Modelo

Nombre de producto:Theatron Agrippa
Serie de producto: Theatron
Codigo: CMS-THAGR
Codigo EAN: 8717249404606

Interface

Interfaz de bus: PCI 2.2 compliant

Chipset

Sound Chipset: C-Media CMI8770
Integrated S/PDIF Input & Output
Full-duplex 8CH DAC/2CH ADC
Support 24bit /96KHz Playback

API

DirectSound™3D: Si
Versión EAX: 2.0
Versión A3D: 1.0
OpenAL: Si

Dimensiones

Ancho: Una ranura
Formato: Tamaño estandar
Tamaño de tarjeta: 154 x 95 x 16 mm

Certificaciones

ROHS: Si
CE: Si

Configuracion de salida / entrada

Optical In: No disponible
Optical Out: 1x
Coaxial In: No disponible
Coaxial Out: 1x
Line In: Si
Microphone In: Si
Front Out: Si
Rear Out: Si
Back Sourround Out: Si
Center/Woofer Out: Si
Aux In: Si
CD In: Si
MIDI Output: Si (es necesario de un adaptador, no esta incluido)
SPDIF I/O: Si
CD SPDIF: Si

Incluye

Tarjeta de sonido Club 3D Theatron Agrippa DTS 7.1
1.5m Cable Optico Digital
Driver y E-Manual CD
Guia de instalacion rapida

Requisitos del sistema

Requisitos del sistema

Intel® Pentium® III or AMD™ Athlon™ or compatible
256MB of system memory (1024MB recommended)
Motherboard with one available PCI 2.1 or higher spec. compliant PCI slot
Hard Disk Drive supporting UDMA 66/100 and 5400rpm or faster
Installation software requires CD-ROM drive, a keyboard, a mouse and a display
DVD playback requires DVD drive and DVD
Blu-ray playback requires Blu-ray drive and Blu-ray disc

Soporte para sistema operativo

Microsoft® Windows® 7 32/64-Bit
Microsoft® Windows® XP 32/64-Bit, MCE
Microsoft® Windows® Vista 32/64-Bit
Microsoft® Windows® 2000
