Maximum resolution:
4K UHD 4096x2160p @60Hz 8Bit and 1920x1080p 3D video @120Hz
Connector 1
Mini DisplayPort™ 1.2 Male
Connector 2
HDMI™ 2.0 Female
Model
Product Name: Mini DisplayPort™ 1.2 to HDMI™ 2.0 4K60Hz UHD Active Adapter
Product Series: Accessories
Weight: 56 gr
Cable length: 180 mm
Item Code: CAC-1170
EAN Code: 8719214470067
UPC Code: 841615100156
Features
• Compliant to DisplayPort™ Specification 1.2 for 1.62Gbps,2.7Gbps and
• 5.4Gbps per lane. Effective video bandwidth 17.28Gbps
• Compliant to HDMI™ Specification 2.0, data rate up to 6Gbps per TMDS
• channel. Total throughput 18Gbps
• Supports full link training and no link training
• Repeater for HDCP 1.3 and HDCP 2.2
• Supports UHD resolutions up to 4096 x 2160p @ 60Hz, 8Bit color
• Supports 3D video support up to 1080p @120Hz
• Supports RGB up to 12 bpc, YCbCr4:4:4 -4:2:2 -4:2:0 up to 12 bpc
• Supports AMD Eyefinity Feature
Compatibility
Supports AMD GCN cards, Nvidia® Maxwell cards and Intel® Skylake HD 5XX series and newer. Not intended for older architectures (such as Intel Haswell HD 4XXX / NVidia Kepler 5xx/6xx series Graphics)
Operating Systems
Windows 10, 8.1, 7 32 & 64 bit
Apple OS X 10.11, 10.10, 10.9, 10.8
In the Box
Club 3D CAC-1170 mDP 1.2 to HDMI™ 2.0 UHD Active Adapter
