Overview

With all the latest features, the Club 3D Radeon™ HD 4350 Noiseless Edition graphics card delivers the best performance you can get for a PCI bus interface. Equipped with HDMI, DVI and VGA out for a wide range of connectivity options. Enjoy a noiseless experience at home, work and play due to the passive cooling system. Club 3D Radeon™ HD 4350 Noiseless Edition is suitable for low profile form factor PC systems and a good choice when you are looking for a feature-rich upgrade to replace integrated onboard graphics.

Key features:

  • DirectX® 10.1
  • Enhanced anti-aliasing (AA) & high performance anisotropic filtering
  • Upscale Beyond 1080p
  • ATI Avivo™ HD video and display technology*
  • Unified Video Decoder 2 (UVD) for Blu-ray™ and HD Video
  • Enhanced DVD Upscaling
  • Dynamic Contrast
  • ATI Stream™ technology
  • HDMI Display Output**
  • HDCP-Capable***

* Feature requires supported video software.
** Native HDMI connector.
*** Requires other compatible components that are HDCP-capable.

PDF Download:

Radeon HD 4350 PCI Edition

Specifications

Model

  • Product Name: Radeon HD 4350 PCI Edition
  • Product Series: Radeon HD4000
  • Item Code: CGA-4352PLI
  • EAN Code: 8717249406860

Interface

  • Bus Interface: PCI

Chipset GPU

  • Chipset: RV710
  • GPU Clock: 594MHz
  • Stream Processors: 80

Multi-GPU

  • Multi-GPU: None

Memory

  • Memory Size: 512MB
  • Memory Interface: 64BIT
  • Memory Type: DDR2
  • Memory Clock: 792MHz

Cooling

  • Cooling Type: Passive Heatsink

3D API

  • DirectX version: 10.1
  • OpenGL: YES

Dimensions

  • Slot Width: 2 Slots
  • Profile: Low profile
  • Card Size: 167*56*32 mm

Output Configuration

  • DVI: 1x Dual Link
  • CRT: 1x
  • HDMI: 1x
  • HDCP ready: YES
  • RAMDAC: 400MHz
  • Max. Res. digital: 2560x1600
  • Max. Res. analog: 2048x1536

Bundle Package Content:

  • Club 3D Radeon™ HD 4350 graphics card
  • 2x low profile brackets
  • Driver & E-Manual CD
  • Quick install guide

System Requirements

System Requirements:

  • Intel®, AMD™ or compatible system processor
  • 512MB of system memory
  • One free PCI slot available on the motherboard is required.
  • CD-ROM drive for software installation
  • 350Watt or greater Power Supply

Operating system support:

  • Microsoft® Windows® XP 32/64-Bit
  • Microsoft® Windows® Vista 32/64-Bit
  • Microsoft® Windows® 7 32/64-Bit
