Overview

Now, more people than ever can experience real innovation in DirectX® 11 gaming with the Club 3D Radeon HD 5750 graphics card. Loaded with advanced technology, this graphics card has the power and premium features you need for fully immersive gameplay. Using ATI Stream technology*, accelerate even the most demanding applications and do more then ever with our PC. Enable realistic visual effects and an explosive HD gaming performance to dominate the competition.

Key features:

Full DirectX® 11 support

DirectX® 11 is the very latest in high-speed, high-fidelity gaming and computing. Featuring technologies like Compute Shaders, Direct2D, Multithreaded Rendering and Tessellation, DirectX® 11 can enable not just more visually stunning games, but significant performance improvements in some of your favorite websites and everyday applications.

tl_files/club3d/uploads/en/content/DirectX 11 Radeon.jpg

AMD HD3D technology

Armed and ready to enable new levels of true-to-life Stereo 3D game play, Club 3D Radeon™ graphics solutions offer the latest features and incredible performance.

tl_files/club3d/uploads/en/content/HD3D RADEON.jpg

Dual AMD CrossFireX™ multi-GPU technology

ATI CrossFireX technology allows you to expand your system’s graphics capabilities. It allows you the ability to scale your system’s graphics horsepower as you need it, supporting up to two Club 3D Radeon™ HD graphics cards, making this the most scalable gaming platform ever.

tl_files/club3d/uploads/en/content/CrossFire_X_2.jpg

ATI Avivo HD Video & Display technology

Watch stunning high definition entertainment from your PC, whether Blu-ray™/HD DVD discs or other HD sources. Be thrilled by immersive high definition big-screen PC gaming, and view ultra high quality photo images and Internet videos. Get universal connectivity support for HDTVs and high-res PC displays, with HDCP1 support for reliably playing the latest HD entertainment on your Windows media PC. Step up to ATI Avivo™ HD, and discover your ultimate PC entertainment experience.

tl_files/club3d/uploads/en/content/AMD AVIVO HD 2.jpg

PCI Express 2.1

PCI Express 2.1 offers maximum transfer rate to meet the enormous need for bandwidth of games and latest 3D applications, while maintaining compatibility with existing PCI Express to provide the highest level of support.

Accelerate your digital world with ATI Stream Technology

Using AMD Stream Technology, Club 3D owners of AMD Radeon™ graphics processors can unlock the potential in their digital applications and see improvements with their overall computing experience. AMD Stream can help accelerate next-generation entertainment, gaming and productivity, applications from companies such as ArcSoft and CyberLink.

Integrated HD audio controller

Output protected high bit rate 7.1 channel surround sound over HDMI with no additional cables required
Supports AC-3, AAC, Dolby TrueHD and DTS Master Audio formats.

PDF Download:

Radeon HD 5750 specification sheet (EN)

High Resolution Image:

Radeon HD 5750

Specifications

Model

Product Name: Radeon HD 5750
Product Series: Radeon HD5000
Item Code: CGAX-57524I
EAN Code: 8717249407577

Interface

Bus Interface: PCI Express 2.1

Chipset

GPU Chipset: Juniper LE
GPU Clock: 700MHz
Stream Processors: 720

Multi-GPU

Multi-GPU: CrossFireX

Memory

Memory Size: 1024MB
Memory Interface: 128BIT
Memory Type: GDDR5
Memory Clock: 4600MHz

Cooling

Cooling Type: Active Fansink

3D API

DirectX version: 11
OpenGL: YES

Dimensions

Slot Width: 2 Slots
Profile: Standard profile
Card Size: TBA mm

Output Configuration

DVI: 1x Dual Link
CRT: 1x
HDMI: 1x
HDCP ready: YES
RAMDAC: 400MHz
Max. Res. digital: 2560x1600
Max. Res. analog: 2048x1536

Bundle

Club 3D Radeon™ HD 5750 graphics card
Driver & E-Manual CD
Quick install guide

System Requirements

System Requirements

PCI Express® based PC is required with one x16 lane graphics slot available on the motherboard
Minimum of 450 Watt or greater power
supply with one 75W 6-pin PCI Express power connector recommended. Club 3D
recommends CSP-S600 600Watt Switching Power Supply.
Minimum 1GB of system memory
Installation software requires CD-ROM drive

Operating system support

Microsoft® Windows® XP 32/64-Bit
Microsoft® Windows® Vista 32/64-Bit
Microsoft® Windows® 7 32/64-Bit
