Radeon Graphics
AMD Catalyst configuration software
CrossFire Ready (via software mode)
DirectX 11.1
7.1 HD Surround Sound
4096 Ultra HD
OpenGL 4.2
OpenCL 1.2
Dual-Link DVI-D
Single slot
PCI Express 3.0
UEFI compliant

Club 3D Radeon HD 7750

Club 3D presents its latest addition to the Radeon HD 7000 series, the Radeon HD 7750 4096MB DDR3 graphic card. The Radeon HD 7750 4096MB DDR3 offers an incredible amount of memory frame buffer for those budget minded gamers.

The card utilizes a custom cooler design with a single slot 50mm fan that ensures the card to remain cool at 57 ⁰C on average when gaming, extending the lifespan of the card and operate stable at high speed. The Radeon HD 7750 DDR3 card also consume 3W less power under load and is fully powered through the PCI Express interface, meaning it does not require an external power connector, offering more compatibility with older generation power supplies. Run games at full HD by upgrading from your old onboard graphic card and boost performance by up to 7x compared to previous generation Radeon graphic cards.* Add more and faster memory and enhance your internet experience, watching online video's, photo and video editing has never been this smooth and fast, experience true speed with the Club 3D Radeon HD 7750 4096MB DDR3.

(*) Performance compared vs Radeon HD 4550


The Radeon HD 7750 offers great performance with the GPU clocked at 800 MHz and the memory at 1600 MHz, with an overclocking headroom at 900 MHz for GPU and 2000 MHz on memory and Beyond.


The Club 3D Radeon™ HD 7750 graphics cards are intended for gamers who never settle. Equipped with AMD Graphics Core Next Architecture and the latest power management technology, the Club 3D Radeon™ HD 7750 is primed to enable astonishing performance and breathtaking image quality, making it the only solution for gamers who demand the best.


GCNGraphics Core Next (GCN) Architecture and AMD App Acceleration

A revolutionary new architecture. Jump right into GPGPU applications today with Microsoft C++ AMP™ and OpenCL™ for spectacular performance with the GCN architecture. From video editors to Internet browsers, AMD App Acceleration™ is a supercharger for everyday applications. The Club 3D Radeon™ HD 7750 was engineered for the revolution in GPU                                                                                                                                               compute.


AMD is introducing with the Southern Islands chipset their long idle power saving technology. Now the graphics card can turn off most of its functional units of the GPU, when they are unused, leaving only the PCI Express bus and other components active. This as a result, reduce the power consumption from 16W at idle to under 3W in long idle, a power level low enough that ZeroCore Power shuts off the fan as there is no heat generated further saving energy.

ZeroCore Power will put CrossFire™ grapics cards in ZCP when not in use.


AMD HD3D™ is a technology designed to enable stereoscopic 3D support in games, movies and/or photos. Additional hardware (e.g., 3D-enabled panels, 3D-enabled glasses/emitter, Blu-ray 3D drive) and/or software (e.g., Blu-ray 3D discs, 3D middleware, games) are required for the enablement of stereoscopic 3D. Not all features may be supported on all components or systems—check with your component or system manufacturer for specific model capabilities and supported technologies. AMD HD3D™ technology is enabled on AMD Radeon™ HD 7000 Series GPUs and above using Catalyst 12 or later.



AMD HD 7000 Series App Acceleration


4 years after the introduction of PCI-E 2.0, the all new PCI-E 3.0 specification is now introduced. Providing 1GB/sec per lane bidirectional, which for a X16 device means 16 GB/sec, doubling 8 GB/sec on the previous generation.

Club 3D Radeon HD 7750 4096MB DDR3FAST HDMI technology

With the introduction of the HD 6000 Series, HDMI 1.4a implementation allows the graphics card to enable Stereo 3D on HDTVs or monitor displays, this same feature is also found on the new HD 7750. Now with the introduction of HDMI support for 4K x 2K displays, the HD 7750 is now able to run 4K x 2K displays (max resolution 4096x3112) over HDMI along with being able to support 1080p Stereo 3D at 120fps (60Hz/eye), with the current standard set at 48fps (24Hz/eye).


AMD CrossFireX™ multi-GPU technology

CrossFire Ready

AMD CrossFireX™ technology allows you to expand your system’s graphics capabilities. AMD CrossFireX™ technology is the ultimate multi-GPU performance gaming platform. Unlocking game-dominating power, AMD CrossFireX™ harnesses the power of two or more discrete graphics cards working in parallel to dramatically improve gaming performance. With Club 3D Radeon™ HD graphics cards ready for practically every budget and the flexibility to combine two GPUs*, AMD CrossFireX™ is the perfect multi-GPU solution for those who demand the best.

* CrossFire via software mode

Recommended adapters (active links)

PDF Download:

Club 3D Radeon HD 7750 Product Information sheet (EN)

High Resolution Image:

Club 3D Radeon HD 7750 High resolution image



Product Name: Radeon HD 7750
Product Series: Radeon HD 7000
Item Code: CGAX-7758Z
EAN Code: 8717249411338


Bus Interface: PCI Express 3.0


GPU Chipset: Cape Verde Pro
GPU Clock: 800 MHz
Stream Processors: 512


Multi-GPU: Dual CrossFire Ready (via software mode)


Memory Size: 4096MB
Memory Interface: 128BIT
Memory Type: DDR3
Memory Clock: 1600 MHz


Cooling Type: Active Fansink


Idle: 16W
Idle ZCP mode enabled: 3W
Maximum load: 58W


DirectX version: 11.1
OpenGL version: 4.2
OpenCL version: 1.2


Slot Width: 1 Slot
Profile: Standard profile
Card Size: 168 x 107 x 18 mm


Card Weight: 231 grams

Output Configuration

DVI: 1x Dual-Link DVI-D
VGA: 1x
HDMI: 1x version 1.4a
HDCP ready: YES
Maximum Resolution VGA: 2048x1536
Maximum Resolution Single-Link DVI: 1920x1200
Maximum Resolution Dual-Link DVI: 2560x1600
Maximum Resolution HDMI 1.4a: 4096x3112

In the package

Club 3D Radeon HD 7750 graphic card
Driver & E-Manual CD
Quick install guide

System Requirements

System Requirements

PCI Express® 1.1 based PC or higher with one single-width X16 lane graphics slot available on the motherboard is required
Minimum of 450 Watt or greater power supply
Club 3D recommends CSP-S600 600 Watt Switching Power Supply
Minimum 1024MB of system memory (2048MB recommended)
Installation software requires CD-ROM drive, a keyboard, a mouse and a display
DVD playback requires DVD drive and DVD disc
Blu-ray playback requires Blu-ray drive and Blu-ray disc
For an AMD CrossFireX™ system, a second Club 3D Radeon™ HD 7750 series graphic card*, an AMD CrossFireX Ready motherboard. * CrossFire available in software mode

Operating system support

Microsoft® Windows® XP 32/64-Bit, MCE *
Microsoft® Windows® Vista 32/64-Bit
Microsoft® Windows® 7 32/64-Bit

Eyefinity is only supported on Microsoft® Windows® Vista 32/64-Bit and Microsoft® Windows® 7 32/64-bit Operating Systems
