AMD LOGOClub 3D Radeon™ HD 7790

Based on the award-winning GCN Architecture, Club 3D Radeon™ HD 7700 Series GPUs are built to game with the world’s most advanced 28nm GPU design. And it’s packed with incredible features: AMD App Acceleration for snappy performance in everyday programs, or ultra-resolution gaming with AMD Eyefinity technology are just the beginning! These are the world’s most advanced graphics. For everyone.

The Club 3D Radeon HD 7790 features the all brand new Bonaire XT GPU, boosting numerous advantages over the existing products such as 40% more stream processors and texture units than the HD 7770 GHz Edtiion, increased bandwith when compared to both HD 7750 and HD 7770 GHz Edition thanks to higher clock at 6000 MHz and 1GB of GDDR5 memory. This GPU has an impressive 1030 MHz which provides incredible gaming performance.



Award

Great Value5 out of 5 starsHWT - Product of the yearZeden tres bonBang for buckEditor's ChoiceGoed

'13Series

After the Award winning "Poker Series", it is now time for the introduction of "White Label" '13Series. With our expertise to build you the ultimate graphics card to tailor your gaming preferences, Club 3D is taking a next step and offer you the quality you expect in the most cost effective manner. No extra's bundled, and as a result you save money you can spend on building your ultimate rig.



GAMING PERFORMANCE

GAMING

Club 3D has chosen 3DMark as a essential tool used by millions of gamers, hundreds of hardware review sites to meassure the gaming performance of the Club 3D Radeon HD 7790 against the Club 3D Radeon DH 7770 GHz Edition. We use this test as we feel represent an accurate method how the Club 3D Radeon HD 7790 performs. The resolution, and enough stress on the graphics product to provide a quality experience and overall playability.

3DMark Fire Strike performance table

3DMark

Primary Benchmark System
Motherboard: MSI X79A-GD65 8D
Memory: Corsair Vengeance (4x4GB) DDR3-1600 (9-9-9-24)
HDD: 1TB Seagate Barracuda 7200.11 (ST3100033AS)
Display: Dell 3007WFP-HC
Display Driver: Version  AMD Catalyst 7790 RC1 Press Driver AMD Catalyst 13.3 Beta 1
Graphics card: Club 3D Radeon HD 7770 GHz Edition
Graphics card 2: Club 3D Radeon HD 7790

Introduction to TressFX Technology

Since the dawn of the 3D era, characters in your favorite games have largely featured totally unrealistic hair: blocky and jagged, often without animation that matches your character’s movements. Many games have attempted to disguise the problem with short haircuts, updos, or even unremovable helmets. But why? Simply: realistic hair is one of the most complex and challenging materials to accurately reproduce in real-time. Convincingly recreating a head of lively hair involves drawing tens of thousands of tiny and individual semi-transparent strands, each of which casts complex shadows and requires anti-aliasing. Even more challengingly, these calculations must be updated dozens of times per second to synchronize with the motion of a character.

TRESSFX BANNER

LARA

TressFX Hair revolutionizes Lara Croft’s locks by using the DirectCompute programming language to unlock the massively-parallel processing capabilities of the Graphics Core Next architecture, enabling image quality previously restricted to pre-rendered images. Building on AMD’s previous work on Order Independent Transparency (OIT), this method makes use of Per-Pixel Linked-List (PPLL) data structures to manage rendering complexity and memory usage.

AMD's TressFX Hair in Tomb Raider

AMD EYEFINITY TECHNOLOGY

Multi-display technology for gaming, productivity, and entertainment

EYEFINITY

Supporting multiple independent display outputs simultaneously, AMD Eyefinity technology delivers innovative graphics display capabilities enabling massive desktop workspaces and ultra-immersive visual environments for the ultimate panoramic computing experience.

PCI EXPRESS 3.0

4 years after the introduction of PCI-E 2.0, the all new PCI-E 3.0 specification is now introduced. Providing 1GB/sec per lane bidirectional, which for a X16 device means 16 GB/sec, doubling 8 GB/sec on the previous generation.

PCI Express 3.0

FAST HDMI technology

With the introduction of the HD 6000 Series, HDMI 1.4a implementation allows the graphics card to enable Stereo 3D on HDTVs or monitor displays, this same feature is also found on the new HD 7790. Now with the introduction of HDMI support for 4K x 2K displays, the HD 7790 is now able to run 4K x 2K displays (max resolution 4096x3112) over HDMI along with being able to support 1080p Stereo 3D at 120fps (60Hz/eye), with the current standard set at 48fps (24Hz/eye).

HDMI

AMD CrossFireX™ multi-GPU technology

CrossFire Ready

AMD CrossFireX™ technology allows you to expand your system’s graphics capabilities.AMD CrossFireX™ technology is the ultimate multi-GPU performance gaming platform. Unlocking game-dominating power, AMD CrossFireX™ harnesses the power of two or more discrete graphics cards working in parallel to dramatically improve gaming performance. With Club 3D Radeon™ HD graphics cards ready for practically every budget and the flexibility to combine two GPUs, AMD CrossFireX™ is the perfect multi-GPU solution for those who demand the best.

Recommended adapters (active links)

CrossFire Interconnect - CAC-CB



Multi-Monitor
21.6 Gbps bandwidth

AdapterThis graphics card is optimized for AMD Eyefinity™ technology and supports the latest generation of display connectivity.

The graphics card features 1 DisplayPort 1.2 outputs with 21.6 Gbps of bandwidth and high bit rate audio. The graphics card features support for by up to six screens simultaneously using AMD Eyefinity™ technology. DisplayPort gives you the flexibility to "Daisy Chain" multiple monitors with a single output and also convert to any desired output. Please refer to Club 3D accessories website for more information.


Recommended adapters (active links)

DisplayPort to Active DVI Dual Link - CAC-1051
DisplayPort to DVI Single-Link cable - CAC-1052
DisplayPort to VGA - CAC-1002
DisplayPort to HDMI - CAC1001
DisplayPort to Single Link DVI-D - CAC-1000




Protective capsPROTECTIVE CAPS

Dust can collect inside unused video outputs and Electro-Static-Discharge (ESD) by touching the PCB with bare hands while not grounding yourself can be harmful to a graphic card. To protect against dust and ESD Club 3D provides protective caps on the video outputs, CrossFire connector(s) and PCB goldfinger of the graphic card and can prolong the lifespan of your graphic card by up to 65%.

PDF Download:

Club 3D Radeon HD 7790 '13Series Product Information sheet (EN)

High Resolution Image:

Club 3D Radeon HD 7790 '13Series High Resolution Image

Specifications

Model

Product Name: Radeon HD 7790 GHz Edition
Product Series: Radeon HD 7000
Item Code: CGAX-779213
EAN Code: 8717249411789

Interface

Bus Interface: PCI Express 3.0

Chipset

GPU Chipset: Bonaire XT
GPU Clock: 1030 MHz
Stream Processors: 896

Multi-GPU

Multi-GPU: Dual CrossFire Ready

Memory

Memory Size: 1024MB
Memory Interface: 128BIT
Memory Type: GDDR5
Memory Clock: 6000 MHz

Cooling

Cooling Type: Active Fansink

TDP

Idle: 16W
Idle ZCP mode enabled: 3W
Maximum load: 85W

3D API

DirectX version: 11.1
OpenGL version: 4.2
OpenCL version: 1.2

Dimensions

Slot Width: 2.5 Slots
Profile: Standard profile
Card Size: 186 x 125 x 42 mm

Weight

Card Weight: TBA

Output Configuration

DVI: 1x Dual-Link DVI-I
DVI: 1x Dual-Link DVI-D
HDMI: 1x version 1.4a
DisplayPort: 1x version 1.2
HDCP ready: YES
RAMDAC: 400MHz
Maximum Resolution analog: 2048x1536 (via Dual-Link DVI to VGA adapter)
Maximum Resolution Single-Link DVI: 1920x1200
Maximum Resolution Dual-Link DVI: 2560x1600
Maximum Resolution HDMI 1.4a: 4096x3112
Maximum Resolution DP 1.2: 4096x2160
Maximum Outputs Simultaneously: 3

In the package

Club 3D Radeon HD 7790 GHz Edition graphics card
Driver & E-Manual CD
Quick install guide

System Requirements

System Requirements

PCI Express® 1.1 based PC or higher with one dual-width X16 lane graphics slot available on the motherboard is required
Minimum of 500 Watt or greater power supply with one 75W 6 pin PCI Express supplementary power connector
Club 3D recommends CSP-S600 600 Watt Switching Power Supply
Minimum 1024MB of system memory (2048MB recommended)
Installation software requires CD-ROM drive, a keyboard, a mouse and a display
DVD playback requires DVD drive and DVD
Blu-ray playback requires Blu-ray drive and Blu-ray disc
For an AMD CrossFireX™ system, a second Club 3D Radeon™ HD 7790 series graphic card, an AMD CrossFireX Ready motherboard and one Club 3D CrossFireX™ Interconnect Bridge (Club 3D itemcode: CAC-CB) are required

Operating system support

Microsoft® Windows® 8 32/64-Bit
Microsoft® Windows® 7 32/64-Bit
Microsoft® Windows® Vista 32/64-Bit
Microsoft® Windows® XP 32/64-Bit, MCE*

Eyefinity is only supported on Microsoft® Windows® Vista 32/64-Bit and Microsoft® Windows® 7 32/64-bit Operating Systems
