Club 3D Radeon HD 7970 royalAceClub 3D takes a giant leap and destroys the competition with the release of the most quiet, cool and brutally fast Club 3D Radeon HD 7970 royalAce graphic card, the latest addition to the PokerSeries family.

Get the best of the best with Club 3D's PokerSeries, the Radeon HD 7970 royalAce offers great performance by breaking the GHz barrier on the GPU, clocking at 1050MHz, making it amazingly fast, up to 7% faster in games when compared to the reference HD 7970 GHz Edition. The Radeon HD 7970 royalAce is a quiet card, achieving 31.5 dB on idle, 38 dB at load, making it the ideal choice for gaming and multimedia. By utilizing a custom cooler design with a dual fan and four high performance heatpipes it ensures the card to remain cool at 71 ⁰C on average when gaming. A Dual BIOS toggle switch offers overclocking potential for the most demanding gamer and overclocking enthusiast.

The Club 3D Radeon HD 7970 royalAce embodies the maturity of the 28nm process, and the scalability of the Graphics Core Next architecture. This card also features an extension to AMD Powertune technology called "Boost", which allows the GPU to dynamically adjust both voltage and clockspeed above the reference clock of 1050MHz+.







UNPRECEDENTED GAMING PERFORMANCE

3DMark 11 Performance3DMARK 11

3DMark 11 is the latest version of the world's most popular benchmark. Designed to measure your PC's gaming performance 3DMark 11 makes extensive use of all the new features in DirectX 11 including tessellation, compute shaders and multi-threading. Trusted by gamers worldwide to give accurate and unbiased results, 3DMark 11 is the best way to consistently and reliably test DirectX 11 under game-like loads.







Battlefield 3 PerformanceBATTLEFIELD 3

Battlefield 3 is the world's most popular first person shooter and set the benchmark for real-time gaming performance introducing state-of-the-art technologies that allows you to experience superior animation, unparalleled lighting and specials effects, delivering enhanced visual quality, a grand sense of scale, massive destruction and incredible gameplay.

With PokerSeries Club 3D offers a new level of special gamecards that delivers the best performance, newest features and best coolers. The royalAce present our highest demands.



HD 7970 comparisonCoolStream High Performance Cooling Technology

If you expect above average performance of your Graphics card, Club 3D CoolStream High Performance Cooling Technology is just the kind of high performance that you have been looking for.

Club 3D royalAce features high performance heatpipes that keeps the components cool and outperforms standard cooling solutions. Paired with a unique fan blade design it increases airflow while reducing noise. The result is a dramatic increase of performance for your gaming and multimedia experience.



Super OverclockExtreme Gamers require Extreme performance. The PokerSeries royalAce GPU's has been cherry-picked for extreme performance. Club 3D has developed a custom PCB to accommodate faster speeds and thermal dissipation. At 50MHz faster than the reference clock of 1000MHz, you will be running faster, efficient and more reliable out of the box without you having to do anything at all. You can be assured that the royalAce series won't let you down.



royalFlushroyalFlush OverClock Software

royalFlush, Club 3D's own overclocking software lets you fully make use of your graphic card as YOU want it. Overclock your graphic card to unlock even higher performance. Find the most efficient settings for your card!

Download and Learn more here





The Best Games
Club 3D offers the newest most demanding AAA game titles with this card, there is no question. Find out more here.


SHOWCASE RADEON HD 7970 SERIES REALTIME DX11 GRAPHICS

With 2048 stream processors and coupled with a 384 bit GDDR5 memory bus will provide 4.04 TFLOPs of computing performance, representing no comprise for the active gamer, who desires technology that enables an incredible gaming experience on the latest and most demanding title.

NEW FEATURES

Eyefinity 2.0EYEFINITY 2.0

Eyefinity™ 2.0 technology features all-new support for Stereo 3D, universal bezel compensation and brand new display configurations which allows the user to configure custom resolutions and the ability to relocate the Windows task bar to an arbitrary screen.




DDMADIGITAL MULTI-POINT AUDIO (DDMA)

The next step in audio output from a graphics card. Traditionally video cards has been able to output audio through the HDMI port and audio has been restricted to to a single device, be it a monitor, HDTV or a receiver.

With DDMA now you can send audio to multiple devices via the DisplayPort combined with the HDMI.

Imagine a video conferencing where each attendee is mapped to a monitor and with DDMA set on each monitor speaker set.

GCNGraphics Core Next (GCN) Architecture and AMD App Acceleration

A revolutionary new architecture. Jump right into GPGPU applications today with Microsoft C++ AMP™ and OpenCL™ for spectacular performance with the GCN architecture. From video editors to Internet browsers, AMD App Acceleration™ is a supercharger for everyday applications. The Club 3D Radeon™ HD 7970 royalAce was engineered for the revolution in GPU compute.

ZCP

ZEROCORE POWER

AMD is introducing with the Southern Islands chipset their long idle power saving technology. Now the graphics card can turn off most of its functional units of the GPU, when they are unused, leaving only the PCI Express bus and other components active. This as a result, reduce the power consumption from 15W at idle to under 3W in long idle, a power level low enough that ZeroCore Power shuts off the fan as there is no heat generated further saving energy.

ZeroCore Power will put CrossFire™ grapics cards in ZCP when not in use.


HD3DAMD HD3D

AMD HD3D™ is a technology designed to enable stereoscopic 3D support in games, movies and/or photos. Additional hardware (e.g., 3D-enabled panels, 3D-enabled glasses/emitter, Blu-ray 3D drive) and/or software (e.g., Blu-ray 3D discs, 3D middleware, games) are required for the enablement of stereoscopic 3D. Not all features may be supported on all components or systems—check with your component or system manufacturer for specific model capabilities and supported technologies. AMD HD3D™ technology is enabled on AMD Radeon™ HD 7000 Series GPUs and above using Catalyst 12 or later.


AMD POWERTUNE TECHNOLOGY


AMD HD 7000 Series App Acceleration

PCI EXPRESS 3.0

4 years after the introduction of PCI-E 2.0, the all new PCI-E 3.0 specification is now introduced. Providing 1GB/sec per lane bidirectional, which for a X16 device means 16 GB/sec, doubling 8 GB/sec on the previous generation.

PCI Express 3.0

HDMIFAST HDMI technology

With the introduction of the HD 6000 Series, HDMI 1.4a implementation allows the graphics card to enable Stereo 3D on HDTVs or monitor displays, this same feature is also found on the new HD 7970. Now with the introduction of HDMI support for 4K x 2K displays, the HD 7970 is now able to run 4K x 2K displays (max resolution 4096x3112) over HDMI along with being able to support 1080p Stereo 3D at 120fps (60Hz/eye), with the current standard set at 48fps (24Hz/eye).



Dual BIOS SwitchDual BIOS Toggle Switch

The Club 3D Radeon™ HD 7970 royalAce comes with a toggle switch.
This switch allows you to switch between two separate BIOS versions on your Club 3D Radeon™ HD 7970 royalAce graphics card.

Setting 1: factory defaults
Setting 2: unprotected

The graphics card comes standard at 1050 MHz GPU clock speed with an overclocking headroom at 1.1GHz and Beyond.



Quad AMD CrossFireX™ multi-GPU technology

Quad CrossFireX Ready

AMD CrossFireX™ technology allows you to expand your system’s graphics capabilities. AMD CrossFireX™ technology is the ultimate multi-GPU performance gaming platform. Unlocking game-dominating power, AMD CrossFireX™ harnesses the power of two or more discrete graphics cards working in parallel to dramatically improve gaming performance. With Club 3D Radeon™ HD graphics cards ready for practically every budget and the flexibility to combine two, three or four GPUs, AMD CrossFireX™ is the perfect multi-GPU solution for those who demand the best.

Recommended adapters (active links)

CrossFire Interconnect - CAC-CB


Multi-Monitor 21.6 Gbps bandwidth

This graphics card is optimized for AMD Eyefinity™ technology and supports the latest generation of display connectivity.

The graphics card features 2 Mini DisplayPort 1.2 outputs with 21.6 Gbps of bandwidth and high bit rate audio. Mini DisplayPort gives you the flexibility to "Daisy Chain" multiple monitors with a single output and also convert to any desired output. Please refer to Club 3D accessories website for more information.

Outputs

Recommended adapters (active links)

Mini DisplayPort to HDMI cable - CAC-1101
Mini DisplayPort to DVI-D Single-Link cable - CAC-1100
Mini DisplayPort to Active DVI Single-Link Cable - CAC-1152

PROTECTIVE CAPS


Dust can collect inside unused video outputs and Electro-Static-Discharge (ESD) by touching the PCB with bare hands while not grounding yourself can be harmful to a graphic card. To protect against dust and ESD Club 3D provides protective caps on the video outputs, CrossFire connector(s) and PCB goldfinger of the graphic card and can prolong the lifespan of your graphic card by up to 65%.

Protective caps

PDF Download:

Club 3D Radeon HD 7970 royalAce Product Information sheet (EN)

High Resolution Image:

Club 3D Radeon HD 7970 royalAce High resolution image

Specifications

Model

Product Name: Radeon HD 7970 royalAce
Product Series: Radeon HD 7000
Item Code: CGAX-7977SO
EAN Code: 8717249411185

Interface

Bus Interface: PCI Express 3.0

Chipset

GPU Chipset: Tahiti XT2
GPU Clock: 1050 MHz
Boost clock: 1100 MHz
Stream Processors: 2048

Multi-GPU

Multi-GPU: Quad CrossFire Ready

Memory

Memory Size: 3072MB
Memory Interface: 384BIT
Memory Type: GDDR5
Memory Clock: 6000 MHz (4x1500MHz)

Cooling

Cooling Type: Active

TDP

Idle: 15W
Idle ZCP mode enabled: 3W
Maximum load: 250W

3D API

DirectX version: 11.1
OpenGL version: 4.2
OpenCL version: 1.2

Dimensions

Slot Width: 2 Slots
Profile: Standard profile
Card Size: 268 x 122 x 36 mm

Weight

Card Weight: 698 grams

Output Configuration

DVI: 1x Dual-Link DVI-I
HDMI: 1x version 1.4a
Mini DisplayPort: 2x version 1.2
HDCP ready: YES
RAMDAC: 400MHz
Maximum Resolution analog: 2048x1536 (via Dual-Link DVI to VGA adapter)
Maximum Resolution Single-Link DVI: 1920x1200
Maximum Resolution Dual-Link DVI: 2560x1600
Maximum Resolution HDMI 1.4a: 4096x3112
Maximum Resolution Mini DP 1.2: 4096x2160
Maximum Outputs Simultaneously: 4

In the package

Club 3D Radeon HD 7970 royalAce graphic card
Club 3D CrossFireX bridge (CAC-CB) interconnect cable
Club 3D knob hanger
Driver & E-Manual CD
Quick install guide

System Requirements

System Requirements

PCI Express® 1.1 based PC or higher with one dual width X16 lane graphics slot available on the motherboard is required
Minimum of 500 Watt or greater power supply with one 75W 6 pin PCI Express connector and one 150W 8 pin PCI Express supplementary power connector
Club 3D recommends CSP-700CB 700 Watt Switching Power Supply
Minimum 1024MB of system memory (2GB recommended)
Installation software requires CD-ROM drive, a keyboard, a mouse and a display
DVD playback requires DVD drive and DVD
Blu-ray playback requires Blu-ray drive and Blu-ray disc
For an AMD CrossFireX™ system, a second Club 3D Radeon™ HD 7970 series graphic card, an AMD CrossFireX Ready motherboard and one Club 3D CrossFireX™ Interconnect Bridge (Club 3D itemcode: CAC-CB) are required

Operating system support

Microsoft® Windows® 8 32/64-Bit
Microsoft® Windows® 7 32/64-Bit
Microsoft® Windows® Vista 32/64-Bit
Microsoft® Windows® XP 32/64-Bit, MCE *

Eyefinity is only supported on Microsoft® Windows® Vista 32/64-Bit and Microsoft® Windows® 7 32/64-bit Operating Systems
