Radeon Graphics
AMD Catalyst configuration software
Quad CrossFire Ready
Eyefinity 2.0
DirectX 11.1
7.1 HD Surround Sound
1080p Full HD
OpenGL 4.2
OpenCL 1.2
2x Mini DisplayPort 1.2
Dual Link DVI-I
DiRT3 Full version game included

Club 3D Radeon HD 7970The Club 3D Radeon™ HD 7970 is the first graphics cards using a 28nm GPU and supporting Direct3D 11.1 that will initially ship with Windows 8.

With 2048 stream processors and coupled with a 384 bit GDDR5 memory bus will provide 3.79TFLOPs of computing performance, representing no comprise for the active gamer, who desires technology that enables an incredible gaming experience on the latest and most demanding title.


The Club 3D Radeon™ HD 7970 graphics card comes standard at 925 MHz GPU clock speed with an overclocking headroom at 1 GHz and Beyond.


Eyefinity 2.0EYEFINITY 2.0

Eyefinity™ 2.0 technology features all-new support for Stereo 3D, universal bezel compensation and brand new display configurations which allows the user to configure custom resolutions and the ability to relocate the Windows task bar to an arbitrary screen.



The next step in audio output from a graphics card. Traditionally video cards has been able to output audio through the HDMI port and audio has been restricted to to a single device, be it a monitor, HDTV or a receiver.

With DDMA now you can send audio to multiple devices via the DisplayPort combined with the HDMI.

Imagine a video conferencing where each attendee is mapped to a monitor and with DDMA set on each monitor speaker set.

GCNGraphics Core Next (GCN) Architecture and AMD App Acceleration

A revolutionary new architecture. Jump right into GPGPU applications today with Microsoft C++ AMP™ and OpenCL™ for spectacular performance with the GCN architecture. From video editors to Internet browsers, AMD App Acceleration™ is a supercharger for everyday applications. The Club 3D Radeon™ HD 7970 was engineered for the revolution in GPU                                                                                                                                               compute.


AMD is introducing with the Southern Islands chipset their long idle power saving technology. Now the graphics card can turn off most of its functional units of the GPU, when they are unused, leaving only the PCI Express bus and other components active. This as a result, reduce the power consumption from 15W at idle to under 3W in long idle, a power level low enough that ZeroCore Power shuts off the fan as there is no heat generated further saving energy.

ZeroCore Power will put CrossFire™ grapics cards in ZCP when not in use.


AMD HD3D™ is a technology designed to enable stereoscopic 3D support in games, movies and/or photos. Additional hardware (e.g., 3D-enabled panels, 3D-enabled glasses/emitter, Blu-ray 3D drive) and/or software (e.g., Blu-ray 3D discs, 3D middleware, games) are required for the enablement of stereoscopic 3D. Not all features may be supported on all components or systems—check with your component or system manufacturer for specific model capabilities and supported technologies. AMD HD3D™ technology is enabled on AMD Radeon™ HD 7000 Series GPUs and above using Catalyst 12 or later.


AMD HD 7000 Series App Acceleration


4 years after the introduction of PCI-E 2.0, the all new PCI-E 3.0 specification is now introduced. Providing 1GB/sec per lane bidirectional, which for a X16 device means 16 GB/sec, doubling 8 GB/sec on the previous generation.

PCI Express 3.0

HDMIFAST HDMI technology

With the introduction of the HD 6000 Series, HDMI 1.4a implementation allows the graphics card to enable Stereo 3D on HDTVs or monitor displays, this same feature is also found on the new HD 7970. Now with the introduction of HDMI support for 4K x 2K displays, the HD 7970 is now able to run 4K x 2K displays (max resolution 4096x3112) over HDMI along with being able to support 1080p Stereo 3D at 120fps (60Hz/eye), with the current standard set at 48fps (24Hz/eye).

Dual BIOS SwitchDual BIOS Toggle Switch

The Club 3D Radeon™ HD 7970 comes with a toggle switch.
This switch allows you to switch between two separate BIOS versions on your Club 3D Radeon™ HD 7970 graphics card.

Setting 1: unprotected
Setting 2: factory defaults

The graphics card comes standard at 925 MHz GPU clock speed with an overclocking headroom at 1GHz and Beyond

1GHz Ready


Quad AMD CrossFireX™ multi-GPU technology

Quad CrossFireX Ready

AMD CrossFireX™ technology allows you to expand your system’s graphics capabilities. AMD CrossFireX™ technology is the ultimate multi-GPU performance gaming platform. Unlocking game-dominating power, AMD CrossFireX™ harnesses the power of two or more discrete graphics cards working in parallel to dramatically improve gaming performance. With Club 3D Radeon™ HD graphics cards ready for practically every budget and the flexibility to combine two, three or four GPUs, AMD CrossFireX™ is the perfect multi-GPU solution for those who demand the best.

21.6 Gbps bandwidth

This graphics card is optimized for AMD Eyefinity™ Technology and supports the latest generation of display connectivity.

The graphics card features 2 Mini DisplayPort 1.2 outputs with 21.6 Gbps of bandwidth and high bit rate audio. Mini DisplayPort gives you the flexibility to "Daisy Chain" multiple monitors with a single output and also convert to any desired output. Please refer to Club 3D accessories website for more information.

OutputsRecommended adapters (active links)

Mini DisplayPort to HDMI cable CAC-1101
Mini DisplayPort to DVI-D Single-Link cable CAC-1100
Mini DisplayPort to Active DVI Single-Link Cable CAC-1152

PDF Download:

Club 3D Radeon HD 7970 Product information sheet (EN)
Club 3D Radeon HD 7970 Dual BIOS information sheet (EN)

High Resolution Image:

Club 3D Radeon HD 7970 High resolution image



Product Name: Radeon HD 7970
Product Series: Radeon HD 7000
Item Code: CGAX-7977
EAN Code: 8717249410621


Bus Interface: PCI Express 3.0


GPU Chipset: Tahiti XT
GPU Clock: 925 MHz
Stream Processors: 2048


Multi-GPU: Quad CrossFire Ready


Memory Size: 3072MB
Memory Interface: 384BIT
Memory Type: GDDR5
Memory Clock: 5500 MHz


Cooling Type: Active Vapor-Chamber Fansink


Idle: 15W
Idle ZCP mode: 3W
Maximum load: 250W


DirectX version: 11.1
OpenGL version: 4.2
OpenCL version: 1.2


Slot Width: 2 Slots
Profile: Standard profile
Card Size: 278*107*34 mm


Card Weight: 1111 grams

Output Configuration

DVI: 1x Dual Link DVI-I
VGA: via Dongle
HDMI: 1x version 1.4a
Mini DisplayPort: 2x version 1.2
HDCP ready: YES
Maximum Resolution analog: 2048x1536 (via Dual-Link DVI to VGA adapter)
Maximum Resolution Single-Link DVI: 1920x1200
Maximum Resolution Dual-Link DVI: 2560x1600
Maximum Resolution HDMI 1.4a: 4096x3112
Maximum Resolution Mini DP 1.2: 4096x2160

In the package

Club 3D Radeon HD 7970 graphics card
Club 3D CrossFireX bridge (CAC-CB) interconnect cable
DiRT3 Full version game (Voucher)
Club 3D UltraAV Mini DisplayPort to Active DVI Single-Link cable (CAC-1152enables the connection of your Mini DisplayPort source to an Active DVI Single Link supported television, monitor or projector.
Driver & E-Manual CD
Quick install guide

System Requirements

System Requirements

PCI Express® 1.1 based PC or higher with one dual width X16 lane graphics slot available on the motherboard is required
Minimum of 500 Watt or greater power supply with one 75W 6 pin PCI Express connector and one 150W 8 pin PCI Express supplementary power connector
Club 3D recommends CSP-700CB 700 Watt Switching Power Supply
Minimum 1024 MB of system memory (2048MB recommended)
Installation software requires CD-ROM drive, a keyboard, a mouse and a display
DVD playback requires DVD drive and DVD
Blu-ray playback requires Blu-ray drive and Blu-ray disc
For an AMD CrossFireX™ system, a second Club 3D Radeon™ HD 7970 series graphic card, an AMD CrossFireX Ready motherboard and one Club 3D CrossFireX™ Interconnect Bridge (Club 3D itemcode: CAC-CB) are required

Operating system support

Microsoft® Windows® 8 32/64-Bit
Microsoft® Windows® 7 32/64-Bit
Microsoft® Windows® Vista 32/64-Bit
Microsoft® Windows® XP 32/64-Bit, MCE *

Eyefinity is only supported on Microsoft® Windows® Vista 32/64-Bit and Microsoft® Windows® 7 32/64-bit Operating Systems
