Overview

Radeon Graphics
AMD Catalyst configuration software
Quad CrossFire Ready
Eyefinity 2.0
AMD HD3D
DirectX 11.1
7.1 HD Surround Sound
4096 Ultra HD
OpenGL 4.2
OpenCL 1.2
Mini DisplayPort 1.2
Mini DisplayPort 1.2
FAST HDMI 1.4a
Single-Link DVI-D
Dual-Link DVI-I
CoolStream High Performance Cooling Technology
PCI Express 3.0

Club 3D Radeon HD 7990 Dual GPU

Club 3D unveils its brand new Radeon HD 7990 Dual GPU graphic card, the latest and fastest addition to its highly praised Radeon HD 7000 series. The Radeon HD 7990 Dual GPU graphic card is a real performance beast and features the power of two Radeon HD 7970 series processors on a single card. Prepare to be blown away by the incredible speed of the Radeon HD 7990 Dual GPU in the hottest DirectX 11 games with its processing power of 2x2048 Stream Processors and 6144MB memory. Experience amazing graphics with Morphological Anti-Aliasing (MLAA 2.0) and Adaptive Anti-Aliasing technologies that help smooth out jagged edges without compromising performance.

Club 3D Radeon HD 7990 Dual GPUThe Club 3D Radeon HD 7990 Dual GPU delivers exceptional performance at 40% faster than the Radeon HD 7970 GHz board and 45% faster than the standard Radeon HD 7970 and delivers incredible performance at great value. Combine two Club 3D Radeon HD 7990 Dual GPU graphic cards to create a Quad CrossFire configuration and take your gaming performance to extreme levels.

(*) Performance compared versus standard Radeon HD 7970

Featuring a non-reference design, the 10 high performance heatpipes keep the GPU temperatures at a stable 45 degrees when running in idle and 65 degrees under load (3DMark 11 on Extreme preset settings) and the three fans (2x 92mm and 1x 80mm) are designed to operate under extreme load conditions and provide a reasonable 31.5dBA in idle and 33.9dBA under load.

Club 3D Radeon HD 7990 Dual GPU front view

Club 3D Royal Service

Club 3D offers great service and to extend this service, we are offering with the Radeon HD 7990 series a Royal Service – Direct Warranty and Support. It is very simple, all you have to do is register your product with Club 3D and you will receive a customer number which you will need to claim direct service support. In case of failure Club 3D will collect the card at your place and will return the replacement within one week all expenses covered.

Procedure
Contact Club 3D per e-mail; support@club-3d.com. Send in the Serial Number of the Card and Proof of Purchase. You will receive an unique customer number which entitles you with Club 3D Royal Service.

AWARD

Goed Chip.de ranking Hexus Performance award

Incredible Performance

Club 3D Radeon HD 7990 Dual GPU performance comparison

3DMark 11

3DMark 11 is the latest version of the world's most popular benchmark. Designed to measure your PC's gaming performance 3DMark 11 makes extensive use of all the new features in DirectX 11 including tessellation, compute shaders and multi-threading. Trusted by gamers worldwide to give accurate and unbiased results, 3DMark 11 is the best way to consistently and reliably test DirectX 11 under game-like loads.

Battlefield 3

Battlefield 3 is the world's most popular first person shooter and set the benchmark for real-time gaming performance introducing state-of-the-art technologies that allows you to experience superior animation, unparalleled lighting and special effects, delivering enhanced visual quality, a grand sense of scale, massive destruction and incredible gameplay.

Tested on the following hardware configuration:
CPU: AMD PhenomII X4 955 (3.2GHz)
Motherboard: MSI 990FXA-GD80
Memory: Kingston 2x2GB DDR3-1600
PSU: Club 3D 1000Watt (CSP-X1000CB)
Operating System: Windows 7 Ultimate
Driver: Catalyst 9.1 Beta Cap1
Benchmark: 3DMark 11 X score, Battlefield 3 average frames per second


CoolStream High Performance Cooling TechnologyIf you expect above average performance of your Graphics card, Club 3D CoolStream High Performance Cooling Technology is just the kind of high performance that you have been looking for.

Club 3D CoolStream features high performance heatpipes that keeps the components cool and outperforms standard cooling solutions. Paired with a unique fan blade design it increases airflow while reducing noise. The result is a dramatic increase of performance for your gaming and multimedia experience.

Engineered for Extreme Performance

Dual BIOSExtreme Gamers require extreme performance. The two Radeon HD 7970 GPU's on the Radeon HD 7990 Dual GPU have been cherry-picked for extreme performance and efficiency. Club 3D has developed a customized PCB to accommodate faster speeds and thermal dissipation.

The card features a Dual BIOS that caters to the extreme user and overclocking enthusiast. With the standard BIOS at 2x900 MHz reference GPU clock you will be running faster, efficient and more reliable out of the box. Unlock the GPU to 2x925 MHz clock speeds and beyond with a push of a button. You can be assured that the Radeon HD 7990 Dual GPU won't let you down.



The Best Games
Club 3D offers the newest most demanding AAA game titles with this card, there is no question. Find out more here.


Showcase Radeon HD 7990 Series Realtime DX11 Graphics

With 2x2048 stream processors and coupled with a 2x384 bit GDDR5 memory bus will provide 8.04 TFLOPs of computing performance, representing no comprise for the active gamer, who desires technology that enables an incredible gaming experience on the latest and most demanding title.

New Features

Eyefinity 2.0Eyefinity 2.0

Eyefinity™ 2.0 technology features all-new support for Stereo 3D, universal bezel compensation and brand new display configurations which allows the user to configure custom resolutions and the ability to relocate the Windows task bar to an arbitrary screen.




DDMADigital Multi-Point Audio (DDMA)

The next step in audio output from a graphics card. Traditionally video cards has been able to output audio through the HDMI port and audio has been restricted to to a single device, be it a monitor, HDTV or a receiver.

With DDMA now you can send audio to multiple devices via the DisplayPort combined with the HDMI.

Imagine a video conferencing where each attendee is mapped to a monitor and with DDMA set on each monitor speaker set.

GCNGraphics Core Next (GCN) Architecture and AMD App Acceleration

A revolutionary new architecture. Jump right into GPGPU applications today with Microsoft C++ AMP™ and OpenCL™ for spectacular performance with the GCN architecture. From video editors to Internet browsers, AMD App Acceleration™ is a supercharger for everyday applications. The Club 3D Radeon™ HD 7990 Dual GPU was engineered for the revolution in GPU compute.

ZeroCore Power

Power consumption


AMD introduced with the Southern Islands chipset their long idle power saving technology. Now the graphic card can turn off most of its functional units of the GPUs, when they are unused, leaving only the PCI Express bus and other components active. This as a result, reduce the power consumption from 30W at idle to under 3W in long idle, a power level low enough that ZeroCore Power shuts off the fan as there is no heat generated further saving energy.

ZeroCore Power will put CrossFire™ grapic cards in ZCP when not in use.









AMD HD3D

HD3D


AMD HD3D™ is a technology designed to enable stereoscopic 3D support in games, movies and/or photos. Additional hardware (e.g., 3D-enabled panels, 3D-enabled glasses/emitter, Blu-ray 3D drive) and/or software (e.g., Blu-ray 3D discs, 3D middleware, games) are required for the enablement of stereoscopic 3D. Not all features may be supported on all components or systems—check with your component or system manufacturer for specific model capabilities and supported technologies. AMD HD3D™ technology is enabled on AMD Radeon™ HD 7000 Series GPUs and above using Catalyst 12 or later.


AMD PowerTune technology

AMD HD 7000 Series App Acceleration

PCI Express 3.0

4 years after the introduction of PCI-E 2.0, the all new PCI-E 3.0 specification is now introduced. Providing 1GB/sec per lane bidirectional, which for a X16 device means 16 GB/sec, doubling 8 GB/sec on the previous generation.

PCI Express 3.0

HDMIFAST HDMI technology

With the introduction of the HD 6000 Series, HDMI 1.4a implementation allows the graphics card to enable Stereo 3D on HDTVs or monitor displays, this same feature is also found on the new HD 7970. Now with the introduction of HDMI support for 4K x 2K displays, the HD 7970 is now able to run 4K x 2K displays (max resolution 4096x3112) over HDMI along with being able to support 1080p Stereo 3D at 120fps (60Hz/eye), with the current standard set at 48fps (24Hz/eye).



Quad AMD CrossFire™ multi-GPU technology

AMD CrossFire™ technology allows you to expand your system’s graphics capabilities. AMD CrossFire™ technology is the ultimate multi-GPU performance gaming platform. Unlocking game-dominating power, AMD CrossFire™ harnesses the power of two discrete graphic cards working in parallel to dramatically improve gaming performance. With Club 3D Radeon™ HD graphic cards ready for practically every budget and the flexibility to combine two or four GPUs, AMD CrossFire™ is the perfect multi-GPU solution for those who demand the best.

Recommended adapters (active links)

CrossFire Interconnect - CAC-CB

Multi-Monitor
21.6 Gbps bandwidth

This graphics card is optimized for AMD Eyefinity™ technology and supports the latest generation of display connectivity.

The graphics card features 2 Mini DisplayPort 1.2 outputs with 21.6 Gbps of bandwidth and high bit rate audio. Mini DisplayPort gives you the flexibility to "Daisy Chain" multiple monitors with a single output and also convert to any desired output. Please refer to Club 3D accessories website for more information.

Video outputs
Recommended adapters (active links)

Mini DisplayPort to HDMI cable - CAC-1101
Mini DisplayPort to DVI-D Single-Link cable - CAC-1100
Mini DisplayPort to Active DVI Single-Link Cable - CAC-1152

Extendable support pod

To enhance graphic card durability and to relieve pressure from the graphic card and the PCI Express slot of the motherboard, Club 3D developed an extendable support pod that works as a pillar underneath the graphic card, taking away any concerns about the bending of the graphic card or motherboard that may occur under the heavy load of hefty graphic cards. The suppod pod can be adjusted in height from 62mm to up to 150mm, maximizing compatibility when using a different PCI Express slot than the first slot on the motherboard.

Club 3D Radeon HD 7990 Dual GPU front view Club 3D Radeon HD 7990 Dual GPU side view

Protective caps

To enhance graphic card durability and to relieve pressure from the graphic card and the PCI Express slot of the motherboard, Club 3D developed an extendable support pod that works as a pillar underneath the graphic card, taking away any concerns about the bending of the graphic card or motherboard that may occur under the heavy load of hefty graphic cards. The suppod pod can be adjusted in height from 62mm to up to 150mm, maximizing compatibility when using a different PCI Express slot than the first slot on the motherboard.

Protective caps

PDF Download:

Club 3D Radeon HD 7990 Dual GPU Product Information sheet (EN)

High Resolution Image:

Club 3D Radeon HD 7990 Dual GPU High Resolution image

Specifications

Model

Product Name: Radeon HD 7990 Dual GPU
Product Series: Radeon HD 7000
Item Code: CGAX-7999
EAN Code: 8717249411321

Interface

Bus Interface: PCI Express 3.0

Chipset

GPU Chipset: 2xTahiti XT
GPU Clock: 2x900 MHz
OC clock: 2x925 MHz
Stream Processors: 2x2048

Multi-GPU

Multi-GPU: Quad CrossFire Ready

Memory

Memory Size: 6144MB (2x3072MB)
Memory Interface: 2x384BIT
Memory Type: GDDR5
Memory Clock: 5500 MHz (4x1375MHz)

Cooling

Cooling Type: Active, CoolStream High Performance Cooling technology
Fans: 1x 80mm, 2x 92mm
Heatpipes: 10

TDP

Idle: 30W
Idle ZCP mode enabled: 3W
Maximum load: 500W

3D API

DirectX version: 11.1
OpenGL version: 4.2
OpenCL version: 1.2

Dimensions

Slot Width: 3 Slots
Profile: Standard profile
Card Size: 308 x 137 x 62 mm

Weight

Card Weight: 1792 grams

Output Configuration

DVI: 1x Dual-Link DVI-I, 1x Single-Link DVI-D
HDMI: 1x version 1.4a
Mini DisplayPort: 2x version 1.2
HDCP ready: YES
RAMDAC: 400MHz
Maximum Resolution analog: 2048x1536 (via Dual-Link DVI to VGA adapter)
Maximum Resolution Single-Link DVI: 1920x1200
Maximum Resolution Dual-Link DVI: 2560x1600
Maximum Resolution HDMI 1.4a: 4096x3112
Maximum Resolution Mini DP 1.2: 4096x2160
Maximum Outputs Simultaneously: 4

In the package

Club 3D Radeon HD 7990 Dual GPU graphic card
Club 3D CrossFireX bridge (CAC-CB) interconnect cable
Club 3D Extendable support pod
Club 3D knob hanger
Driver & E-Manual CD
Quick install guide

System Requirements

System Requirements

PCI Express® 1.1 based PC or higher with one triple-width X16 lane graphics slot available on the motherboard is required
Minimum of 850 Watt or greater power supply with three 150W 8 pin PCI Express supplementary power connectors
Club 3D recommends CSP-X1000CB 1000 Watt Switching Power Supply
Minimum 2048MB of system memory (4GB or higher recommended)
Installation software requires CD-ROM drive (or internet connection), a keyboard, a mouse and a display
DVD playback requires DVD drive and DVD disc
Blu-ray playback requires Blu-ray drive and Blu-ray disc
For an AMD CrossFire™ system, a second Club 3D Radeon™ HD 7990 Dual GPU series graphic card, an AMD CrossFireX Ready motherboard and one Club 3D CrossFireX™ Interconnect Bridge (Club 3D itemcode: CAC-CB) are required

Operating system support

Microsoft® Windows® 8 32/64-Bit
Microsoft® Windows® 7 32/64-Bit
Microsoft® Windows® Vista 32/64-Bit
Microsoft® Windows® XP 32/64-Bit *

Eyefinity is only supported on Microsoft® Windows® Vista 32/64-Bit, Microsoft® Windows® 7 32/64-bit and Microsoft® Windows® 8 32/64-bit Operating Systems
