Overview

Radeon Graphics
AMD Catalyst configuration software
AMD CrossFire Technology
AMD Eyefinity Technology
AMD HD3D
AMD Graphics Core Next
AMD App Acceleration
DirectX 11.1
7.1 HD Surround Sound
4096 Ultra HD
OpenGL 4.2
OpenCL 1.2
Mini DisplayPort 1.2
Mini DisplayPort 1.2
Mini DisplayPort 1.2
Mini DisplayPort 1.2
Dual-Link DVI-I
CoolStream High Performance Cooling Technology
PCI Express 3.0





The Club 3D MALTA: Radeon™ HD 7990 is an uncompromising masterpiece of breathtaking performance. As the world’s fastest and most advanced graphics card, it descends from generations of AMD Radeon graphics cards that wore the same crown. And with a heritage like that, you know what you’re getting: an unparalleled experience wherein gaming is everything... but not the only thing. All hail the new king.

Top PickMust HaveRecommendedGoedPerformanceApprovedPower
PERFORMANCE

You deserve to play the world's most demanding games at the highest resolutions and maximun detail settings, never settle for less.

Engineered as the world's most advanced graphics, is the industries first 28nm GPU design. It features 6GB GDDR5 of RAM, and two of the world's fastest GPU's in a single graphic card, providing 4096 stream processors of raw power.

Equiped with the latest technologies, such as PCI-E 3.0 support, AMD Eyefinity Technology for gaming on three or more displays and the incredible efficient AMD ZeroCore Power technology. Gamers should never settle for anything less.

"Yeah it can play Crysis, faster than anything else"
tl_files/club3d/uploads/en/content/Technology/CLUB 3D/royalFlush/Club-3D_overclock_icon_L.gifSupports royalFlush OverClock software
Download and Learn more here

DESIGN

The Club 3D Radeon™ HD 7990 with the dual slot, three variable speed 80mm low noise fan blade design combined with high performance heatpipes promotes cooler running temperatures under load, which leads to quieter operation, and increases overclocking and performance potential.

The metal backplate significantly improves the pcb strenght and reduces electrical noise.
Designed to push not only the boundaries of DirectX® 11 gaming, the GCN Architecture is also AMD's first design specifically engineered for general computing. Equipped with 64 compute units (4096 stream processors), each containing a scalar coprocessor, AMD's 28nm GPUs are more than capable of handling workloads-and programming languages-traditionally exclusive to the processor. Coupled with the dramatic rise of GPU-aware programming languages like C++ AMP and OpenCL™, the GCN Architecture is truly the right architecture for the right time.
Step beyond the confines of a single monitor and embrace the true potential of PC gaming with the ultra-high resolutions of AMD Eyefinity multi-display technology on the Club 3D Radeon™ HD 7990.

Supporting multiple independent display outputs simultaneously, AMD Eyefinity technology delivers innovative graphics display capabilities enabling massive desktop workspaces and ultra-immersive visual environments for the ultimate panoramic computing experience.
WINDOWS 8

AMD Radeon™ graphics hardware is built to support two key technologies: the DirectX® 11.1 API and a new way of designing GPU drivers called “Windows Display Driver Model 1.2” (WDDM 1.2).1 Together, these technologies enable a range of new features for Windows® 8 and supporting software.
1.Target-Independent Rasterization (DirectX 11.1 required)
TIR is a new rendering path that enables superior anti-aliasing performance in Direct2d-driven applications.

2. Native Stereoscopic 3D (DirectX 11.1 required)
Starting with Windows 8, stereoscopic 3D support will be implemented directly in the operating system with a standardized path for support in future games.

 3. D3D11 Video Playback Improvements
Today, a game’s video content and its interactive content operate on different DirectX levels. Whereas gameplay might be rendered via DirectX 10 or DirectX 11, videos are frequently rendered with DirectX 9. This mixture of API levels makes it difficult for game developers to efficiently implement both types of content, an issue that will be streamlined by the API unification that DirectX 11.1 provides.

4. Screen Rotation
Tablet users are no stranger to rotating their devices between portrait and landscape mode. Compatible AMD Radeon™ graphics solutions and the AMD Catalyst™ graphics driver will utilize WDDM 1.2 to ensure that behaviors like rotating tablets are delivered with optimal consistency.
5. Flicker-free Display Handoff
During the course of operating a GPU, users may have noticed their screen flickering when performing such tasks as: installing a new GPU driver, switching from integrated to discrete graphics, or exiting sleep/hibernate to resume the desktop experience.

Thanks to WDDM 1.2, the AMD Catalyst™ graphics driver may now be smoothly transitioned from one component of the OS to another, which will reduce or eliminate monitor blanking in these scenarios.

6. Optimized Power Consumption
A new mechanism called “DirectFlip” is designed to optimize power consumption for video playback and other full-screen scenarios. It accomplishes this by guaranteeing that alt+tab actions, or overlaid notifications, do not force the computer to perform an inefficient change of rendering modes.

Furthermore, DirectFlip provides optimized memory bandwidth requirements; intelligent management of idle and active power; and smooth transitions from full-screen applications to the desktop.

Support for this feature has been enabled in AMD Catalyst™, and will be available on AMD Radeon™ graphics products that support WDDM 1.2.

Multi Stream Transport (MST) Hub*

The Club 3D MST hub is a hub device that receives a DisplayPort™ 1.2 MST signal from the source device and splits up and routes the video streams independently to each display device. Using this type of configuration also allows the use of non DisplayPortTM 1.2 monitors. Non DisplayPort™ outputs, such as VGA, DVI or HDMI®, the Club 3D MST hub is DP++ and can actively convert the DisplayPort™ signal to the other types of display interface signals.

The MST hub compliments well the Radeon HD 7990, allowing to support of more monitors from the native 5 display support.

*Optional accessory







PDF Download:

Club 3D Radeon HD 7990 Product Information sheet (EN)

High Resolution Image:

Club 3D Radeon HD 7990 High Resolution image

Specifications

Model

Product Name: Radeon HD 7990
Product Series: Radeon HD 7000
Item Code: CGAX-7999XT
EAN Code: 8717249400011

Interface

Bus Interface: PCI Express 3.0

Chipset

GPU Chipset: Malta
GPU Clock: 2x950 MHz (1000 MHz Boost)
Stream Processors: 2x2048

Multi-GPU

Multi-GPU: Quad CrossFire Ready

Memory

Memory Size: 6144MB (2x3072MB)
Memory Interface: 2x384BIT
Memory Type: GDDR5
Memory Clock: 6000 MHz (4x2000 MHz)

Cooling

Cooling Type: Active
Fans: 3x 92mm
Heatpipes: 10

TDP

Idle: 30W
Idle ZCP mode enabled: 3W
Maximum load: 375W

3D API

DirectX version: 11.1
OpenGL version: 4.2
OpenCL version: 1.2

Dimensions

Slot Width: 2 Slots
Profile: Standard profile
Card Size: 312 x 137 x 37 mm

Weight

Card Weight: TBA

Output Configuration

DVI: 1x Dual-Link DVI-I
Mini DisplayPort: 4x version 1.2
HDCP ready: YES
RAMDAC: 400MHz
Maximum Resolution analog: 2048x1536 (via Dual-Link DVI to VGA adapter)
Maximum Resolution Single-Link DVI: 1920x1200
Maximum Resolution Dual-Link DVI: 2560x1600
Maximum Resolution Mini DP 1.2: 4096x2160
Maximum Outputs Simultaneously: 5

In the package

Club 3D Radeon HD 7990 graphic card
Club 3D CrossFireX bridge (CAC-CB) interconnect cable
Club 3D DVI to HDMI (CAC-DMD-HFD3)
Club 3D Mini DisplayPort to SL DVI-D (CAC-1100)
Club 3D knob hanger

Driver & E-Manual CD
Quick install guide

System Requirements

System Requirements

PCI Express® 1.1 based PC or higher with one dual-width X16 lane graphics slot available on the motherboard is required
Minimum of 850 Watt or greater power supply with two 150W 8 pin PCI Express supplementary power connectors
Club 3D recommends CSP-X1000CB 1000 Watt Switching Power Supply
Minimum 2048MB of system memory (4GB or higher recommended)
Installation software requires CD-ROM drive (or internet connection), a keyboard, a mouse and a display
DVD playback requires DVD drive and DVD disc
Blu-ray playback requires Blu-ray drive and Blu-ray disc
For an AMD CrossFire™ system, a second Club 3D Radeon™ HD 7990 Dual GPU series graphic card, an AMD CrossFireX Ready motherboard and one Club 3D CrossFireX™ Interconnect Bridge (Club 3D itemcode: CAC-CB) are required

Operating system support

Microsoft® Windows® 8 32/64-Bit
Microsoft® Windows® 7 32/64-Bit
Microsoft® Windows® Vista 32/64-Bit
Microsoft® Windows® XP 32/64-Bit *

Eyefinity is only supported on Microsoft® Windows® Vista 32/64-Bit, Microsoft® Windows® 7 32/64-bit and Microsoft® Windows® 8 32/64-bit Operating Systems
