CLUB 3D AMD Radeon™ 260X

Unleash the GCN Architecture, meticulously engineered for spectacular DirectX® 11.2 gaming and radical efficiency. Step beyond the confines of a single monitor and embrace the true potential of PC gaming with the ultra-high resolutions of AMD Eyefinity multi-display technology. Redefine the nature of performance with AMD PowerTune technology enabling automatic overclocking and higher framerates. Simply put, the Club 3D AMD Radeon R7 260X is built to perform. Radeon™ is gaming.

KCLUB 3D POKERSERIES

With our new "PokerSeries" Club 3D offers a new level of special gamecards that delivers the best performance, newest features and best coolers. PokerSeries graphic cards present our highest demands

AWARDS

Hardware heaven

GCN

GCN ARCHITECTURE

2nd Generation GCN Architecture for AMD's unified graphics processing and compute cores that allows them to achieve higher utilization for improved performance and efficiency.

GDDR5128 bit GDDR5

With a memory configuration of 2GB 128 bit GDDR5, the R7 260X is capable of providing 104GB/s of bandwidth

PCI

CROSSFIRE

AMD CrossFireX™ technology allows you to expand your system’s graphics capabilities.AMD CrossFireX™ harnesses the power of two or more discrete graphics cards working in parallel to dramatically improve gaming performance. With Club 3D AMD Radeon™ R Series graphics cards ready for practically every budget and the flexibility to combine two GPUs, AMD CrossFireX™ is the perfect multi-GPU solution for those who demand the best.

Increase your gaming performance up to 2x with AMD CrossFire technology, 2.75x for TriFire configurations, or 3.75x with QuadFire configs.

True AudioAMD TRUE AUDIO

The AMD Radeon R7 260X graphics card features the first discrete GPU in the world with a programmable audio pipeline. TrueAudio Technology is designed for game audio artists and engineers to bring their artistic vision beyond sound production into the realm of sound processing.

For as long as game developers have been creating games, game audio engineers have been allocated a limited CPU budget for their audio processing and effects. With the CPU being shared between different tasks audio must be designed for the lowest common denominator and with real‐time performance for audio being extremely important the challenge presented has been immense. What AMD TrueAudio technology provides is guaranteed real‐time performance for tasks on ANY system configured with an enabled GPU, regardless of the installed processor. This is enabled through the integration of multiple Tensilica HiFi EP Audio DSP cores which now provide a dedicated Audio DSP solution for game sound effects and provide engineers the guaranteed real‐time performance and service they require.

Partners

partners

R7 260X

CLUB 3D COOLSTREAM

Keep it cool

If you expect above average performance of your Graphics card, Club 3D CoolStream High Performance Cooling Technology is just the kind of high performance that you have been looking for!

outputs

Display Connectors

Everything you need for your PC

Built in HDMI 1.4a, DisplayPort 1.2 , DVI-I and DVI-D

eyefinity

AMD EYEFINITY

Enjoy the ultimate immersive gaming experience

Supporting multiple independent display outputs simultaneously, AMD Eyefinity technology delivers innovative graphics display capabilities enabling massive desktop workspaces and ultra-immersive visual environments for the ultimate panoramic computing experience

ultraHD4K TV
ULTRAHD 4K Resolution Gaming

GPUs are built for the demands of ultra-high resolution gaming in single and multi-display configurations: get the most out of every square inch of screen.

3 screens

AMD APP ACCELERATION

Remarkable speed and reliability

AMD Radeon™ GPUs with AMD App Acceleration let you run multiple applications at the same time with remarkable speed and reliability. AMD App Acceleration can help reduce slowdowns and stuttering in intensive, media-rich applications. Powered by a set of innovative hardware and software technologies working in concert behind the scenes. AMD App Acceleration gives you enhanced speed and performance beyond traditional graphics and video processing. You can multitask more efficiently and more confidently.

EfficiencyAMD POWERTUNE & ZEROCORE

Efficiency

It's important that great performance and great image quality doesn't come at the expense of a high power bill. Products with the GCN Architecture feature reduced power consumption in the "idle" state.
By dynamically managing the engine clock speeds based on calculations which determine the proximity of the GPU to its TDP limit, AMD PowerTune allows for the GPU to run at higher nominal clock speeds in the high state than otherwise possible.

future of gaming

AMD MANTLE

There's optimization and then there's Mantle

Games enabled with mantle speak the language of the Graphics Core Next architecture to unlock revolutionary performance and image quality. It's a game-changing innovation developed by AMD.

Mantle

raptr

AMD GAMING EVOLVED App, powered by Raptr

Keep your games optimized

Auto-optimization provides the best quality and performance settings for your rig base on data collected from the AMD community. Earn real rewards just for using the Gaming Evolved app while you play. The more you play, the more rewards you'll unlock!
More information at http://raptr.com/amd

UEFI BIOS support

Secure boot

UEFI Secure Boot was created to enhance security in the pre-boot environment. Without UEFI Secure Boot, malware developers can more easily take advantage of several pre-boot attack points, including the system-embedded firmware itself, as well as the interval between the firmware initiation and the loading of the operating system.

Fast boot

When you turn on the computer, the first thing that happens is the system's firmware boots up and gets the basic computer hardware ready for the operating system. On a modern Windows 8 computer, the establishment of the hardware session is a much quicker operation than on older systems because the UEFI system is much more efficient than the BIOS system. To complete the hardware session, the operating system enumerates all available hardware and loads the appropriate drivers, thus ensuring that a solid hardware session is available.

Once the hardware session is ready, the operating system begins its resume operation. Since the resume operation consists only of restoring the kernel session, rather than restoring both the kernel session and the user session, the resume operation can occur much quicker. In addition to this, the resume operation gets a boost from the fact that the operating system is now designed to take advantage of multiple CPU cores when it comes to processing the hibernation data file. (The old resume process only used one.)

tl_files/club3d/uploads/en/content/Graphics cards/R-Series/Computerscreen.pngroyalFlush

royalFlush, Club 3D's own overclocking software lets you fully make use of your graphic card as YOU want it. Overclock your graphic card to unlock even higher performance. find the most efficient settings for your card!

MST hub in action

MULTI STREAM TRANSMISSION HUB

Connect multiple monitors through a single DisplayPort output

MST HubCSV-5300

Display evices have always been an integral part of the PC experience. Whether it is in form of a desktop monitor, a notebook's embedded panel or a touch screen of a PC tablet, display devices play a vital role in defining the users visual experience.

The Multi Stream Transmission Hub is a hub that can transfer a DisplayPort signal into 3 separate signals. Because of this 3 screens can be added to your setup and can even form an Eyefinity setup.

More info, click here





PDF Download:

Radeon R7 260X royalKing

High Resolution Image:

Club 3D Radeon R7 260X royalKing high resolution image

Specifications

Model

Product Name: R7 260X
Product Series: R7
Item Code: CGAX-R726X6O
EAN Code: 8717249400424

Interface

Bus Interface: PCI Express 3.0

Chipset

GPU Chipset: Bonaire XTX
GPU Clock: 1160 MHz
Stream Processors: 896

Multi-GPU

Multi-GPU: Dual CrossFire Ready

Memory

Memory Size: 2048MB
Memory Interface: 128BIT
Memory Type: GDDR5
Memory Clock: 6600 MHz

Cooling

Cooling Type: Active, CoolStream

TDP

Idle: 15W
Idle ZCP mode enabled: 3W
Maximum load: 105W

3D API

DirectX version: 11.2 capable graphics
OpenGL version: 4.2
OpenCL version: 1.2

Dimensions

Slot Width: 2 Slots
Profile: Standard profile
Card Size: 224x127x39 mm

Weight

Card Weight: TBA

Output Configuration

DVI: 1x Single-Link DVI-D 1x Dual-Link DVI-I
HDMI: 1x version 1.4a
DisplayPort: 1x version 1.2
HDCP ready: YES
RAMDAC: 400MHz
Maximum Resolution Single-Link DVI: 1920x1200
Maximum Resolution Dual-Link DVI: 2560x1600
Maximum Resolution HDMI 1.4a: 4096x3112
Maximum Resolution DP 1.2: 4096x2160
Maximum Outputs Simultaneously: 4
Maximum Display support: 6 (Via DisplayPort and using the MST Hub, please refer to CSV-5300

In the package

Club 3D AMD R7 260X graphic card
Club 3D knob hanger
Driver & E-Manual CD
Quick install guide

Feature summary:

  • PCI Express 3.0 x16 bus interface
  • DirectX® 11.2-capable graphics
  • OpenGL 4.2 support
  • Partially Resident Texture (PRT) support (Ultra-high quality texture streaming technology)
Image quality enhancement technology
  • Up to 24x multi-sample anti-aliasing
  • Adaptive anti-aliasing
  • Enhanced Quality Anti-Aliasing (EQAA)
  • Morphological Anti-Aliasing (MLAA 2)
  • DirectX® 9/10/11 Super Sample Anti-Aliasing (SSAA)
  • Automatic LOD adjustment (Requires AMD CatalystTM 12.4 or higher)
  • 16x angle invariant anisotropic texture filtering
AMD Eyefinity multi-display technology
  • Up to 6 displays supported with DP1.2 MST Hubs
  • Independent resolutions, refresh rates, color controls, and video overlays
  • Display grouping (Combine multiple displays to behave like a single large display)
AMD App Acceleration
  • Supports OpenCLTM 1.2, DirectCompute 11 & Microsoft C++ AMP
  • Double Precision Floating Point
AMD HD Media Accelerator
Unified Video Decoder (UVD)
  1. H.264
  2. VC-1
  3. MPEG-2 (SD & HD)
  4. MVC (Blu-ray 3D)
  5. MPEG-4 Part 2 (DivX/Xvid)
  6. Adobe Flash
  7. DXVA 1.0 & 2.0 support
  8. WMV HD
Video Codec Engine (VCE)
  • Multi-stream hardware H.264 encoder
  • Full-fixed mode: 1080p @ 60 FPS encoding
  • Hybrid mode: Stream Processor-assisted encoding
Enhanced Video Quality features
  • Advanced post-processing and scaling
  • Deblocking
  • Denoising
  • Automatic deinterlacing
  • Mosquito noise reduction
  • Edge enhancement
  • 3:2 pulldown detection
Advanced video color correction
  • Brighter whites processing (Blue Stretch)
  • Independent video gamma control
  • Flesh tone correction
  • Color vibrance control
  • Dynamic contrast
  • Dynamic video range control
AMD HD3D technology
  • Stereoscopic 3D display/glasses support
  • Blu-ray 3D support
  • Stereoscopic 3D gaming
  • 3rd party Stereoscopic 3D middleware software support
AMD CrossFireTM multi-GPU technology
  • Supports dual GPU performance scaling

Cutting-edge integrated display support
  • DisplayPort 1.2
  • Max resolution: 4096x2160 @ 60 Hz per display
  • Multi-Stream
  • 21.6 Gbps bandwidth (HBR2)
  • High bit-rate audio
  • Quad HD/4K/UHDTV display support
  • 1080p60 Stereoscopic 3D

HDMI® (With 4K, 3D, x.v.ColorTM and Deep Color)
  • Max resolution: 4096x2160 @ 30 Hz
  • 1600p60 Stereoscopic 3D
  • Quad HD/4k video support
Dual-link DVI with HDCP
  • Max resolution: 2560x1600
 VGA
  • Max resolution: 2048x1536

Advanced audio capabilities
  • DDM Audio
  • 7.1-channel audio bitstreaming via HDMI® or DisplayPort
  • Supports LPCM, AC-3, AAC, Dolby TrueHD and DTS Master Audio formats
AMD PowerPlay power management technology
  • Automatic power management with low power idle states
AMD PowerTune technology
  • Intelligent TDP management technology
  • Dynamic clock speed/performance enhancement for games

AMD ZeroCore Power technology
  • Ultra-low idle power when the system’s display is off
  • Efficient low power mode for desktop work
  • Secondary GPUs in an AMD CrossFireTM technology configuration power down when unneeded

AMD Catalyst driver and HD video configuration software
  • Software support for Windows 8, Windows® 7, Windows Vista®
  • AMD CatalystTM Control Center
  • User interface application for setup, configuration, and access to features of AMD Radeon products
  • Unified graphics display driver (Software enabling other PC programs and devices to use advanced graphics, video, and features of AMD Radeon products)

System Requirements

System Requirements

PCI Express® 1.1 based PC or higher with one dual width X16 lane graphics slot available on the motherboard is required. We recommend a PCI Express® 3.0 based PC for this graphic card.
Minimum of 500 Watt or greater power supply with one 75W 6 pin PCI Express supplementary power connector
Club 3D recommends CSP-S600 600 Watt Switching Power Supply
Minimum of 1024MB system memory (2048MB recommended)
Installation software requires CD-ROM drive, a keyboard, a mouse and a display
DVD playback requires DVD drive and DVD
Blu-ray playback requires Blu-ray drive and Blu-ray disc
For an AMD CrossFireX™ system, a second Club 3D R7 260X graphic card, an AMD CrossFireX Ready motherboard are required

Operating system support

Microsoft® Windows® Vista 32/64-Bit
Microsoft® Windows® 7 32/64-Bit
Microsoft® Windows® 8.1 32/64-Bit

Eyefinity is only supported on Microsoft® Windows® Vista 32/64-Bit, Microsoft® Windows® 7 32/64 BIT and Windows® 8.1 32/64-bit Operating Systems
