Overview

SenseVision
Mac OS X
DirectX 10
1080p Full HD
USB 2.0
OpenGL
Single-Link DVI-I
VGA

USB2.0 to DVI-I graphics devices let you easily add an additional monitor to your notebook PC, desktop and MacBook®. The Club 3D SenseVision USB2.0 to DVI-I Graphics allows you to extend your desktop display beyond 1080p HD resolution displays.

Awards

Editors Choice

How it works

Grab any TV, CRT or LCD monitor, connect it to your SenseVision USB2.0 Graphics and plug the adapter into any standard USB 2.0 port. There's no easier way to add an additional monitor to your PC or Mac®.

Introduction Video

Up to 6 monitors on a desktop or notebook PC

You can add up to six additional monitors to your PC, all you have to do is plug in up to 6 SenseVision CSV-2000D or CSV-2000H in your system for a massive desktop workspace and ultra-immersive visual environments for the ultimate panoramic computing experience.

Sensevision 6 monitor

Up to 4 monitors on OSX Macintosh®

Traditional desktop and notebook systems from Apple Inc. only allows you to connect up to one more display. With SenseVision USB2.0 graphics now you can connect up to 4 display monitors for a massive desktop workspace for OSX. Have you thought of the Spaces feature in OSX with real estate desktop screens ?

OSX 4 Monitors

Why do you need another monitor ?

There are literally countless reasons why increasing your desktop real estate can improve efficiency, enjoyment, and the usability of your computer. With another monitor you can look at more programs at the same time and do real multi-tasking. Imagine surfing the Internet, reading a spreadsheet and being able to read your e-mail, while being involved in an instant messaging conversation at the same time. You can even watch a movie on one screen, without the need to minimize and maximize every window on the other screen. Whether you're a video editor who needs more monitors, a business that wishes to improve efficiency and take control or a home user that wishes to expand the multimedia entertainment value of your computer, Club 3D SenseVision USB2.0 Graphics is the easiest and quickest way to fulfill your multi-tasking needs.

Add up to 6 additional monitors



Plug & Play

Installing a new graphics card can sometimes be time consuming, with SenseVision USB2.0 to DVI-I Graphics, there is no need to open up your computer to install a new graphics card.
Simply connect the SenseVision USB2.0 to DVI-I Graphics to your USB2.0 port and let your Operating System detect the drivers and installation is complete. Installation takes only a minute, it's that easy and fast.*

*Install the software utility for enhanced switching between desktops.

Dual Core Decode Engines

Based upon the award winning DL-195 chipset, bringing high resolutions and industry leading performance for video and 3D graphics, thanks to a dual core decode engine and compression techniques.

Low Power

An energy efficient design provides a very low power graphics solution, with only up to 2.5 Watt at maximum load. Good for the environment, good for your electricity bill.

Ultra-Silent

Completely silent operation thanks to passive cooling solution.

Ultra-Portable

Pocket size 7:6:2 cm, making it convenient for travel.

Compatibility

The driver software and SenseVision USB2.0 Graphics can be run on PCs ranging from Netbooks (e.g. Asus EeePC), Notebooks/Laptops, and Desktops - on processors ranging from Atom N270 based PCs, basic single Core CPUs, and of course the latest Dual, Quad and Hexacore CPUs, including Intel-based Mac's.

Supports Clone or Extended display modes

Can easily clone the main display, or extend left, right, above, or below. Can be rotated left, right, or upside-down.

Windows® Aero Support

Featuring support for Windows® Aero. Enhance your Windows® experience by enabling Windows® Aero, mixing cool graphics with useful new ways to manage your desktop.

OSX Spaces Support

Spaces enhances your desktop real estate by grouping application windows together and let's you easiliy switch between them. Organize each space just the way you want it.

Virtual driver

The SenseVision USB2.0 to DVI-I graphics uses a virtual driver - works with your existing graphics card.
The virtual driver works together with the driver of the existing graphics card in the computer, less USB bandwidth is used, ensuring steady and smooth performance.

PDF Download:

SenseVision USB2.0 to DVI-I Graphics Product Information sheet (EN)

High Resolution Image:

SenseVision USB2.0 to DVI-I Graphics High Resolution image

Specifications

Model

Product Name: SenseVision USB2.0 to DVI-I Graphics
Product Series: SenseVision
Item Code: CSV-2000D
EAN Code: 8717249409601

Interface

Bus Interface: USB2.0

Chipset

Chipset: DL-195

Memory

Memory Size: 16MB
Memory Type: DDR

Cooling

Cooling Type: Passive

TDP

Maximum load: 2.5W

3D API

DirectX 10 support: Yes
OpenGL support: Microsoft® Windows® is supported.
3D (OpenGL) acceleration on Mac OS X is currently not supported.

Dimensions

SenseVision USB2.0 Graphics Size: 63*55*17 mm
USB2.0 cable length: 570 mm

Weight

SenseVision USB2.0 Graphics weight: 70 grams

Output Configuration

DVI: 1x Single Link DVI-I
USB: 1x USB2.0
USB3.0 compatibility: YES
Backwards compatibility USB1.1: YES*
* Please note: When using USB1.1 performance degradation may occur
Max. Res. DVI digital: 2048 x 1152
Max. Res. DVI analog: 2048 x 1152
Max. Res. VGA: 1920 x 1200

In the package

Club 3D SenseVision USB2.0 to DVI-I Graphics
Driver & E-Manual CD
Quick install guide
DVI to VGA adapter (CAA-DMA>CFA)
Mini-USB to USB2.0 cable

System Requirements

System Requirements

PC with 1.2 GHz or higher processor or Macintosh supporting Intel-Mac
512MB of system memory
Available USB2.0 port
30MB of free disk space
Installation software requires CD-ROM drive, a keyboard, a mouse and a display

Existing GPU:
Used for 2D/3D rendering on Windows® Vista and Windows® 7.
Requiring a single Intel®, Nvidia®, or AMD® primary WDDM driver.
For Windows® Vista and Windows® 7 a graphics card with a Windows Experience Index (WEI) score of at least 3 in the “Graphics; Desktop performance for Windows® Aero®” category.

For example:
The use of 6 displays and 6 SenseVision USB2.0 Graphics while running a full screen DVD video requires the following:

PC with 1.8 GHz Dual Core or higher processor or Macintosh supporting Intel-Mac
1024MB of system memory
Six available USB2.0 ports
30MB of free disk space
CD-ROM drive, keyboard, mouse and six displays

Operating System Support

Mac OS X Mountain Lion 10.8
Mac OS X Lion 10.7

Mac OS X Snow Leopard 10.6
Mac OS X Leopard 10.5
Mac OS X Tiger 10.4
Microsoft® Windows® 8
Microsoft® Windows® 7
Microsoft® Windows® Vista
Microsoft® Windows® XP

Microsoft® Windows® XP Media Center Edition
Microsoft® Windows® 2000 SP4

SenseVision drivers - all Operating Systems

Quick Installation Guide
