RESOLUTIONS GUIDE

Possible resolutions of Docking and Video splitters

Displays differ from one another mainly based on the measurement of pixels it supports. Regardless of the screen size, if the pixel stays at this measurement it will be the same display.

HD High Definition is the most familiar format since it has become the standard for the television viewing experience in households around the world. Any video image with a resolution of 1280*720 pixels a 16:9 aspect ration is defined as HD.

Full HD this one is the higher step of HD, and its defined by the support of 1920*1280 pixels. Most consumers have upgraded their TVs and monitors to 720p/1080p to see crisper, more life like images.

Quad HD or 2K (QHD) offers a more detailed view, having four times the vertical resolution of standard 720p HD to 2560*1440 pixels.

Ultra High Definition (UHD) This format delivers what is considered to be the best viewing experience. 4K refers to a horizontal resolution of approximately 4,000 pixels. 4K displays have a resolution of 3840*2160 in an aspect ratio of 16:9 which is four times the Full HD resolution of 1080p

Possible resolutions of Docking and Video splitters

Overview

Table A

HD 1280 x 720 QHD+ 3200 × 1800 6K 6144 x 3160 16K 15360 x 8640
Full HD 1920 x 1080 UHD / 4K 3840 x 2160 8K 7680 x 4320 - -
QHD / 2K 2048 x 1080 4K 4096 × 2160 10K 10240 x 4320 - -
WQHD 2560 × 1440 5K 5120 x 2880 12K 12288 x 6480 - -
Note:The aspect ratio and pixel ratio between monitors and TV may vary. There are also several differences per brand. Consult the specifications of your supplier for this.

Table B
VIDEO SPLITTER ITEM CODE MAX SUPPORTED RESOLUTIONS *
x 2 SCREENS x 3 SCREENS x 4 SCREENS
DISPLAYPORT MST CSV-5200 2 *2560x1440 60H
or
2 *3840x2160 30Hz
3 *1920x1080 60Hzor
2 *2560x1440 60Hz+
1 *1920x1080 60H
4 *1920x1080 60Hz
CSV-6200
CSV-6200H
CSV-3203
CSV-6400
CSV-7300 2 *2560x1440 60Hz 3 *3840x2160 60Hz -
USB TYPE C MST
CSV-1545 3840 x 2160 (Ultra HD 4K) @60hz - -
CSV-1546 3840 x 2160 (Ultra HD 4K) @30hz - -
CSV-1550 2 *3840x2160 60Hz (24bpp) 3 *3840x2160 60Hz
CSV-1556 3840 x 2160 (Ultra HD 4K) @60hz - -
HDMI CSV-1370 4096 x 2160p at 60Hz (input) 4096 x 2160p at 60Hz (input) 4096 x 2160p at 60Hz (input)
CSV-1380 4096 x 2160p at 60Hz - -
THUNDERBOLT 3 CSV-1577 4096x2160p @ 60Hz - -
CSV-1574 3840x2160p @ 60Hz - -
USB TYPE A CSV-1477 4096 x 2160 at 60Hz - -
CSV-1474 3840*2160 60Hz - -
* = The maximum supported resolutions are also dependent on the capacity of the Graphics inside the source system.

Table C
DOCKING ITEM CODE MAX SUPPORTED RESOLUTIONS *
X 1 SCREEN X 2 SCREENS X 3 SCREENS
USB TYPE C CSV-1560 3840*2160 30Hz 1920*1200 60Hz -
CSV-1460 5120*2880 60Hz 3840*2160 60Hz -
CSV-1562 4K60Hz via DP or HDMI 4K60Hz via DP or HDMI 4K30Hz
CSV-1564
+
CSV-1564W100
HDMI™ 4K 30 Hz
DP™ 4K 30 Hz
VGA 1920x1200 60Hz
HDMI™ 4K 30 Hz
DP™ 4K 30 Hz
HDMI™ 4K 30 Hz
-
CSV-1591 4K60Hz via DP or HDMI - -
CSV-1592 4K60Hz via DP or HDMI - -
CSV-1593 4K60Hz 4K/30Hz under MST mode
(Windows™ System)
K/60Hz under SST mode
(Mac™ System ONLY)
-
USB TYPE A CSV-3103D 3840*2160 30Hz 2048*1152 60Hz -
CSV-3104D 3840*2160 30Hz 2048*1152 60Hz -
CSV-3242HD 2048*1152 60Hz 2048*1152 60Hz -
CSV-3242HDA 2048*1152 60Hz 2048*1152 60Hz -
CSV-1460 5120*2880 60Hz 3840*2160 60Hz -
* = The maximum supported resolutions are also dependent on the capacity of the Graphics inside the source system.

Possible resolutions of HDMI™

Possible resolutions of HDMI™
DescriptionResolutionRefresh Rate (Hz)Data RateHDMI Version / Maximum Data Rate*
1.0 - 1.11.2 - 1.2a1.3 - 1.4b2.0 -2.0b2.1
3.96
Gbit/s[b]
3.96
Gbit/s[b]
8.16
Gbit/s[b]
14.4
Gbit/s[b]
42.6
Gbit/s[b]
720p1280 x 72024592,42 Mbit/sYESYESYESYESYES
30740,52 Mbit/sYESYESYESYESYES
601,49 Mbit/sYESYESYESYESYES
1203,08 Gbit/sNOYESYESYESYES
1080p1920 × 1080301,63 Gbit/sYESYESYESYESYES
603,29 Gbit/sYESYESYESYESYES
1206,78 Gbit/sNONOYESYESYES
1448,15 Gbit/sNONOYESYESYES
24014,40 Gbit/sNONONOYESYES
1440p2560 × 1440302,86 Gbit/sNOYESYESYESYES
605,79 Gbit/sNONOYESYESYES
757,29 Gbit/sNONOYESYESYES
12011,92 Gbit/sNONONOYESYES
14414,40 Gbit/sNONONOYESYES
16516,76 Gbit/sNONONONOYES
24025,32 Gbit/sNONONONOYES
4K3840 × 2160306,36 Gbit/sNONOYESYESYES
6012,90 Gbit/sNONONOYESYES
7516,24 Gbit/sNONONONOYES
12025,90 Gbit/sNONONONOYES
14432,24 Gbit/sNONONONOYES
24056,40 Gbit/sNONONONOYES DSC SUPPORT**
5K5120 × 28803011,25 Gbit/sNONONOYESYES
6022,81 Gbit/sNONONONOYES
12046,96 Gbit/sNONONONOYES DSC SUPPORT**
8K7680 × 43203025,18 Gbit/sNONONONOYES
6051,07 Gbit/sNONONONOYES DSC SUPPORT**
120105,11 Gbit/sNONONONOYES DSC SUPPORT**
*Maximum Data Rate means 8b/10b overhead substracted.
**DSC - Display Stream Compression. VESA , the Video Electronics Standard Association published a new standard in 2014 that uses visually lossless image compression to increase the amount of data carried by a display interface data rate , thus saving power.

Possible resolutions of DisplayPort

Possible resolutions of DisplayPort™
Description Resolution Refresh Rate (Hz) Data Rate DisplayPort Version / Maximum Data Rate*
1.0 -1.1a 1.2 -1.2a 1.3 1.4
8.64
Gbit/s[b]
17.28
Gbit/s[b]
25.92
Gbit/s[b]
25.92
Gbit/s[b]
720p 1280 x 720 24 592,42 Mbit/s YES YES YES YES
30 740,52 Mbit/s YES YES YES YES
60 1,49 Mbit/s YES YES YES YES
120 3,08 Gbit/s YES YES YES YES
1080p 1920 × 1080 30 1,63 Gbit/s YES YES YES YES
60 3,29 Gbit/s YES YES YES YES
120 6,78 Gbit/s YES YES YES YES
144 8,15 Gbit/s YES YES YES YES
240 14,40 Gbit/s NO YES YES YES
1440p 2560 × 1440 30 2,86 Gbit/s YES YES YES YES
60 5,79 Gbit/s YES YES YES YES
75 7,29 Gbit/s YES YES YES YES
120 11,92 Gbit/s NO YES YES YES
144 14,40 Gbit/s NO YES YES YES
165 16,76 Gbit/s NO YES YES YES
240 25,32 Gbit/s NO NO YES YES
4K 3840 × 2160 30 6,36 Gbit/s YES YES YES YES
60 12,90 Gbit/s NO YES YES YES
75 16,24 Gbit/s NO YES YES YES
120 25,90 Gbit/s NO NO YES YES
144 32,24 Gbit/s NO NO NO YES DSC SUPPORT**
240 56,40 Gbit/s NO NO NO YES DSC SUPPORT**
5K 5120 × 2880 30 11,25 Gbit/s NO YES YES YES
60 22,81 Gbit/s NO NO YES YES
120 46,96 Gbit/s NO NO NO YES DSC SUPPORT**
8K 7680 × 4320 30 25,18 Gbit/s NO NO YES YES
60 51,07 Gbit/s NO NO NO YES DSC SUPPORT**
120 105,11 Gbit/s NO NO NO NO
**Maximum Data Rate means 8b/10b overhead substracted.
**DSC - Display Stream Compression. VESA , the Video Electronics Standard Association published a new standard in 2014 that uses visually lossless image compression to increase the amount of data carried by a display interface data rate , thus saving power.

Possible resolutions of DVI

Possible resolutions of DVI
Description Resolution Refresh Rate (Hz) Data Rate DVI / Maximum Data Rate*
Single Link Dual Link
3.96
Gbit/s[b]
7.92
Gbit/s[b]
720p 1280 x 720 24 592,42 Mbit/s YES YES
30 740,52 Mbit/s YES YES
60 1,49 Mbit/s YES YES
120 3,08 Gbit/s NO YES
1080p 1920 × 1080 30 1,63 Gbit/s YES YES
60 3,29 Gbit/s YES YES
120 6,78 Gbit/s NO YES
144 8,15 Gbit/s NO NO
240 14,40 Gbit/s NO NO
1440p 2560 × 1440 30 2,86 Gbit/s NO YES
60 5,79 Gbit/s NO YES
75 7,29 Gbit/s NO YES
120 11,92 Gbit/s NO NO
144 14,40 Gbit/s NO NO
165 16,76 Gbit/s NO NO
240 25,32 Gbit/s NO NO
4K 3840 × 2160 30 6,36 Gbit/s NO YES
60 12,90 Gbit/s NO NO
75 16,24 Gbit/s NO NO
120 25,90 Gbit/s NO NO
144 32,24 Gbit/s NO NO
240 56,40 Gbit/s NO NO
5K 5120 × 2880 30 11,25 Gbit/s NO NO
60 22,81 Gbit/s NO NO
120 46,96 Gbit/s NO NO
8K 7680 × 4320 30 25,18 Gbit/s NO NO
60 51,07 Gbit/s NO NO
120 105,11 Gbit/s NO NO
*Maximum Data Rate means 8b/10b overhead substracted.
